ABB i-bus® KNX
WaveLINE Wireless Control – Actuators, RF/KNX Media Converters

WaveLINE-Dimmer Actuator
For wireless switching and dimming of electrical loads. For functions ON/OFF, dimming and
lightscene control. With soft ON/OFF function. With selectable light value storage. For wall
mounted transmitter Waveline 6731-xxx, 6732-xxx and 6733-xxx. For remote control Wave-
LINE 6780. Compatible with WaveLINE KNX gateway TP-RF 6770. Repeater function can be
6704-500
activated for extended range. Controllable up to 32 transmission addresses.
Send/receive frequency: 868 MHz. Free-field range: approx. 100 m. Control element: Adjust-
able potentiometer. Display elements: Status indication of output via LED. Rated voltage:
230 V~, +10 % / –10 %. Rated frequency: 50 Hz. Outputs: 1x dimming channel.
Suitable for: 230 V incandescent lamps. Output voltage: 230 V~. Rated power: 35 – 210 W.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– 6704-500 2CKA006700A0025 0.075 1/10

WaveLINE series/blind actuator with extension unit
For wireless switching of electrical loads. For driving and adjusting blinds/shutters and aw-
nings over radio. Functions via radio control: 2gang switch, blind switch and light scene con-
trol. Functions via extension unit: 2gang switch, blind switch and send radio control tele-
6705-101-500
gram. Operation also possible via conventional push-buttons (2020 US, 2012/6 UK). For wall
mounted transmitter Waveline 6731-xxx, 6732-xxx and 6733-xxx. For remote control Wave-
LINE 6780. For WaveLINE window position sensor 6720-6x. For WaveLINE 6721-xx universal
signalling unit. For Busch-EnergyControl 6762-xx. Compatible with WaveLINE KNX gateway
TP-RF 6770. Controllable up to 32 transmission addresses. Send/receive frequency: 868 MHz.
Free-field range: approx. 100 m. Control element: Adjustable potentiometer. Display ele-
ments: Status indication of output via LED. Rated voltage: 230 V~, +10 % / –10 %. Rated fre-
quency: 50 Hz. Inputs: 2. Polling voltage: 230 V~, Sensing pulse, L-wire. Outputs: 2x Normally
open contact, potential-bound.

Description Mod. Order details Price Weight Pack
14
width 1 piece 1 piece unit
Type code Order code kg pc.
– 6705-101-500 2CKA006700A0042 0.066 1/10

WaveLINE-Media converter TP-RF
Media converter with internal antenna for conversion of KNX RF WaveLine radio signals to
KNX twisted pair networks with 24 channels. For the evaluation and transfer of up to
24 channels each with 4 sub-channels as transmitter or receiver. Simple operation due to
“programming button” and display on the device. Is surface-mounted. The KNX/WaveLine
6770-500
Gateway is powered via KNX and does not require an additional power supply.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– 6770-500 2CKA006770A0002 0.15 1
