14/307

—
ABB i-bus® KNX
WaveLINE Wireless Control – Window Sensor, Universal Detector

LED display WaveLINE
For status display of window handle positions: open = red, closed = green, tilted = yellow.
Direct onsite operation possible for switching / dimming an electrical device depending on
the flush-mounted insert. 4 individual LED display channels. Up to 8 WaveLine transmitters
6730-214 can be taught-in on each LED display channel. Up to 8 WaveLine transmitters can be taughtin
on onsite operation. User-friendly start-up without PC / software. Printed labelling sheet
with 8 different inlay sheets (see labelling sheet 1799 xx). For WaveLINE window position
sensor 6720-6x. For WaveLINE 6721-xx universal signalling unit. For Busch-Watchdog 220
WaveLINE 6747 AGM. For Busch-Universal relay switch insert 6404 U. For universal dimmer
switch insert 6595 U. Free-field range: approx. 100 m. Send/receive frequency: 868 MHz.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
Busch-Duro 2000® SI 1
white – 6730-212 2CKA006730A0001 0.094
Reflex SI 1
alpine white – 6730-214 2CKA006730A0002 0.094

LED display WaveLINE
For status display of window handle positions: open = red, closed = green, tilted = yellow.
Direct onsite operation possible for switching / dimming an electrical device depending on
the flush-mounted insert. 4 individual LED display channels. Up to 8 WaveLine transmitters
6730-24G
can be taught-in on each LED display channel. Up to 8 WaveLine transmitters can be taughtin
on onsite operation. User-friendly start-up without PC / software. Printed labelling sheet
with 8 different inlay sheets (see labelling sheet 1799 xx). For WaveLINE window position
sensor 6720-6x. For WaveLINE 6721-xx universal signalling unit. For Busch-Watchdog 220
WaveLINE 6747 AGM. For Busch-Universal relay switch insert 6404 U. For universal dimmer
switch insert 6595 U. For ABB i-bus® KNX devices 6110 U, 6114 U, 6120 U-102.
Free-field range: approx. 100 m. Send/receive frequency: 868 MHz.
14
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
alpha
platinum – 6730-20 2CKA006730A0007 0.102 1
bronze – 6730-21 2CKA006730A0008 0.102 1
ivory white – 6730-22G 2CKA006730A0009 0.102 1
studio white matt – 6730-24 2CKA006730A0010 0.102 1
studio white glossy – 6730-24G 2CKA006730A0011 0.102 1
palladium – 6730-260 2CKA006730A0005 0.094 1
titanium – 6730-266 2CKA006730A0006 0.094 1
