18/96 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
TwinLine N 55 wall cabinets and floor-standing cabinets
IP55 flanges

Article Unit Type Order code
Membrane flange 1 TZ101 2CPX010450R9999
Material plastic for cable diameter 10 TZ101P10 2CPX010451R9999
2 x 6 - 32.5 mm, 2 x 6 - 25 mm, 4 x 6 - 19 mm, 10 x 6 - 15 mm,
2 x 6 - 12 mm, 31 x 6 - 11 mm, 1 x 6 - 7 mm 100 TZ101P100 2CPX010826R9999
TZ101
Flanges for M-screw joints
Material plastic
1 x M63/M50, 2 x M32/M20, 5 x M25, 5 x M20 1 TZ102 2CPX010452R9999
10 TZ102P10 2CPX010453R9999
TZ102

4 x M20/M25, 18 x M20 1 TZ103 2CPX010454R9999
10 TZ103P10 2CPX010455R9999
TZ103

Flanges with cable sleeves
Material Plastic
Flange with 8 cable sleeves 1 TZ110 2CPX010850R9999
TZ110 For cable diameter 8 x 13 to 34 mm 10 TZ110P10 2CPX010934R9999

Flange with 11 cable sleeves 1 TZ111 2CPX010851R9999
For cable diameters 1 x 14 to 54 mm, 3 x 13 to 34 mm, 10 TZ111P10 2CPX010935R9999
3 x 13 to 26.5 mm, 4 x 5 bis 21 mm
TZ111

Flange with 1 cable sleeve 1 TZ112 2CPX010852R9999
For cable diameter 1 x 14 to 68 mm

TZ112

Flange with 2 cable sleeves 1 TZ104 2CPX010456R9999
For cable diameter 2 x 14 to 68 mm
10 TZ104P10 2CPX010932R9999

TZ104

Flange with 3 cable sleeves 1 TZ105 2CPX010457R9999
For cable diameter 3 x 14 to 54 mm 10 TZ105P10 2CPX010933R9999

TZ105

Locking flanges
18
Material Plastic 1 TZ107 2CPX010460R9999
10 TZ107P10 2CPX010461R9999
TZ107
Material steel sheet 1 TZ106 2CPX010458R9999
For earthed cabinets 10 TZ106P10 2CPX010459R9999
TZ106
