Interior expansion system CombiLine N M M
M
M
Possible applications with WR mounting frame
MBS224 MBS124
Standalone cabinets of the series TwinLine-G, -L, -W/series switching cabinets of the series TriLine , System pro E power
®
Example: Expansion with modules (mounted) on WR mounting frame in the TwinLine- L standalone cabinet
MK209 MK109 TL312G 3/82C TL312G 3/82C
MG203 MT142
NH1
NH1
MM213 MM113
M M M M Delivery form
Modules are delivered ex works
assembled on the WR mounting
frame and installed in the cabinet.
MS224 MS124
+ 5 pcs. ZXM1003 copper rail
Modules (mounted) + WR mounting frame + empty cabinet = standalone distributor
