Interior expansion system CombiLine N
Accessories for NH1-fuse switch disconnector modules

Article Intended use Unit Type Order code
NH1 fuse switch disconnector M(B)T142 - M(B) 1 ZH431 2CPX062958R9999
Rated current (I ) max. 250 A, T343
n
without separator shutters,
with M10 connection screws

ZH431

NH1/NH2 busbar system M(B)T242 1 ZH217 2CPX060446R9999
Copper rails 30 x 5 mm, 3-pole M(B)T342 1 ZH317 2CPX060456R9999
Rated current (I ) 440 A
n
Single-story with M10 connection screws
ZH317

NH1/NH2 busbar system M(B)T243 1 ZH218 2CPX060447R9999
Copper rails 30 x 10 mm, 3-pole M(B)T343 1 ZH318 2CPX060457R9999
Rated current (I ) 630 A
n
Double-story with M10 connection screws
ZH318

Separator shutter 1 x M(B)T142 * 1 ZH438 2CPX062961R9999
Single shutter for NH fuse switch disconnector, 2 x M(B)T242 *
color similar to RAL 7035, for compliance with 3 x M(B)T342 *
the contact protection IPXXC 2 x M(B)T143 *
4 x M(B)T243 *
6 x M(B)T343 *
ZH438

Separator shutter, closed M(B)T142 - M(B) 1 ZH440 2CPX062963R9999
Single shutter instead of NH fuse switch T343
disconnector, color similar to RAL 7035,
for compliance with the contact protection
IPXXC
ZH440

Insulation plate M(B)T142 - M(B) 1 ZX128 2CPX039128R9999
For non-allocated busbar ends with NH1 T343
fuse switch disconnector

ZX128
