18/159

—
Interior expansion system CombiLine N
Busbar system 100 mm, NH00 switch disconnector, M(B)D...52(B)

• Populated with InLine II NH00-100 fuse switch • Busbars for individual cabinet installation
disconnection rails 160 A, Make: ABB • With the EDF and WR mounting frame, defined
• Busbar center distance 100 mm combinations (see info FB width) are possible within
• For 3-pole, horizontally arranged busbars the cabinet. The different busbars can be connected
• With busbar bracket type ZX520 via a connection set
• Rated current (I ) max. 850 A • The NH00 fuse switch disconnection rails are mounted
n ZXM1215
• Important: directly on the copper rails prepared with press-in nuts
1. The cabinet depth is to be noted in the lock area • Set positions are specified for feeding in on copper rails
MD352B Spacing from the front edge of the equipment to the • 3 copper rails are required per module
cover: 29 mm
2. The cable connection when using a middle rail or Copper I Width Kit Mounted
and installed in the cabinet
not installed
rail
cross-profile rail in the direct connection is only mm A n FB mm Unit Type Order code Type Order code
possible to a limited extent with the use of a bridge 30 x 10 630 1 184 1 ZX1210 2CPX042121R9999 ZXM1210 2CPX042230R9999
clamp (plan for connection space, empty module)
• The mounting frame must be ordered separately 2 434 1 1 ZX1211 2CPX042122R9999 ZXM1211 2CPX042231R9999
ZXM1212
ZX1212
2CPX042232R9999
2CPX042123R9999
3
684
• The busbars must b e ordered separately from the module 40 x 10 850 1 184 1 ZX1213 2CPX042124R9999 ZXM1213 2CPX042233R9999
• Not suitable for fire protection housing
• Take additional connection room of at least 150 mm 2 434 1 ZX1214 2CPX042125R9999 ZXM1214 2CPX042234R9999
into consideration 3 684 1 ZX1215 2CPX042126R9999 ZXM1215 2CPX042235R9999
Kit Mounted
Height Width From cabinet depth not installed and installed in the cabinet
• Busbar connection set (panel-panel connector)
RE mm FB mm Equipment PLE EDF* WR* 2 mm Type Order code Type Order code
1
3 450 1 250 3 x NH00 36   215 - - MD152B 2CPX042110R9999 • Important: Note the depth from the cabinet for the
connection set
2 500 8 x NH00 72   215 - - MD252B 2CPX042111R9999 • 3 copper connection sets are required per connection
3 750 12 x NH00 108 -  225 - - MD352B 2CPX042112R9999
• The connection set is not possible for a cabinet depth
* 1 Expansion on EDF mounting frame | * 2 Expansion on WR mounting frame of 215 mm
ZXM1217
Copper Kit Mounted
rail I n Width not installed and installed in the cabinet
mm A mm Unit Type Order code Type Order code
30 x 10 630 230 1 ZX1216 2CPX042119R9999 ZXM1216 2CPX042236R9999
40 x 10 850 230 1 ZX1217 2CPX042120R9999 ZXM1217 2CPX042237R9999

Article Width in mm Suitable for ... Unit Type Order code
ZLBM00-100 50 MD...(H)B, M(B)D... 1 ZE591M 2CPX042959R9999

ZE591M 18
Blanking panels for sealing off reserve spaces 1 ZX964 2CPX042238R9999
100 mm busbar center distance
50 mm width for sealing NH00 strips

ZX964
