Interior expansion system parts
Busbar systems for NH-fuse switch disconnector

Load
break
Rated Copper rail switch
Size NH.. current I n in mm Terminal St. Use for... Unit Type Order code
Busbar systems with access line, line cross-section 35 mm , Line length 500 mm
2
NH00 320 A 20 x 5 mm M8 4 - 1 ZH55 2CPX038559R9999

ZH55
Busbar systems without access line
NH00 320 A 20 x 5 M8 2 MT136B 1 ZH214 2CPX060443R9999
ZH214

NH00 320 A 20 x 5 M8 4 MT236B 1 ZH211 2CPX060440R9999
ZH211

NH00 320 A 20 x 5 M8 6 MT336B 1 ZH311 2CPX060450R9999
ZH311

NH00 320 A 20 x 5 M8 4 MT137B 1 ZH216 2CPX060445R9999

ZH216

NH00 320 A 20 x 5 M8 8 MT237B 1 ZH212 2CPX060441R9999

ZH212
NH00 320 A 20 x 5 M8 12 MT337B 1 ZH312 2CPX060451R9999

ZH312

NH1/NH2 440 A 30 x 5 M10 2 MT242B 1 ZH217 2CPX060446R9999
MT244B
ZH217

NH1/NH2 630 A 30 x 10 M10 4 MT243B 1 ZH218 2CPX060447R9999
MT245B

ZH218
NH1/NH2 440 A 30 x 5 M10 3 MT342B 1 ZH317 2CPX060456R9999
MT344B 18

ZH317
NH1/NH2 630 A 30 x 10 M10 6 MT343B 1 ZH318 2CPX060457R9999
MT345B

ZH318

> Important note: If arranged in a single row, use 3 straight or 3 angled cable lugs to connect to the supply line. If arranged in two rows,
3 angled cable lugs to connect to the supply line.
