Interior expansion system parts
Extension frame/safety terminal cover

Article Use for... Unit Type Order code
Extension frame for covers
For fields with cover brackets 52.5 mm
(ED138, etc.), plastic frame to pre-set
the cover by 25 or 35 mm
External dimensions in mm
1-field width
300 x 250 AG12 1 ED212 2CPX062782R9999
ED212 450 x 250 AG13 1 ED213 2CPX062783R9999
600 x 250 AG14 1 ED214 2CPX062784R9999
750 x 250 AG15 1 ED215 2CPX062785R9999
2-field width
300 x 500 AG22 1 ED222 2CPX062787R9999
450 x 500 AG23 1 ED223 2CPX062788R9999
600 x 500 AG24 1 ED224 2CPX062789R9999
750 x 500 AG25 1 ED225 2CPX062790R9999
3-field width
300 x 750 AG32 1 ED232 2CPX062792R9999
450 x 750 AG33 1 ED233 2CPX062793R9999
600 x 750 AG34 1 ED234 2CPX062794R9999
750 x 750 AG35 1 ED235 2CPX062795R9999
The following is also required per frame:
for 25 mm, increase 1 x ED135P4
for 35 mm, increase 1 x ED139P4
