18/242 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201
—
Internal expansion system with distribution panels
Population of the distribution panels
Distribution panels with DIN rails Distribution panels with DIN rails
for rail-mounted devices for terminal blocks
Equipment: DIN rail 35 x 15 mm for device Equipment: DIN rail 35 x 15 mm for terminal
installation and with hole pattern for the blocks with hole pattern for the wiring system,
wiring system, row spacing 125 mm, with row spacing 125 mm, with plastic covers; for a
plastic covers, cutouts for rail-mounted devices protection-insulated design, use insulators ZK90;
DIN 43880 for 12 PLE (216 mm) per field width To mount the DIN rails to the rear, use ED33 deep
angle piece and DIN rails for installation between
> Wire holder and locking strips see page 127
the mounting frame
> Insulators page 85
> Deep angle piece page 88
Distribution panels with mounting plates Distribution panels with mounting cross-beams
Equipment: Steel sheet metal mounting plate, for device installation without holes
Sendzimir galvanized surface, material thickness Equipment: For every 150 mm, a mounting
2 mm; the mounting plate is mounted on deep cross-beam ZX35 is mounted on ED33 deep
angle piece ED33 and can be variably adjusted angle piece and can be variably adjusted in depth;
in depth; maximum installation depth between the maximum installation depth between the
mounting plate and cover 143 mm, with plastic cross-beam and cover is 143 mm, with plastic
covers (cover closed) covers (cover closed)
Distribution panels as touch protection Distribution panels with busbars
(or to expand with assembly parts) Equipment: 5-Pole busbar system copper
Equipment: Empty panel without installation 12 x 5 mm, busbar spacing 40 mm, with plastic
parts, with plastic covers (covers closed) covers (covers closed)
> Busbar connection terminals page 83
