Subdistribution boards
Fire protection housing – Standing housing, IP44 ,, depth 349 mm
Overall height Locking unit Field width Door hinge Space units External Weight in kg
dimensions in mm
Overall height RE FB (Standard) PLE H × W × D Type Item number
Standing housing IP44 ,, depth 349 mm
8 12 1 right 144 2048 × 398 × 349 1/8SF302 2CPX043290R9999 152
8 12 2 right 288 2048 × 648 × 349 2/8SF302 2CPX043292R9999 206
8 12 3 right 432 2048 × 898 × 349 3/8SF302 2CPX043294R9999 259
9 13 1 right 156 2198 × 398 × 349 1/9SF302 2CPX043304R9999 163
9 13 2 right 312 2198 × 648 × 349 2/9SF302 2CPX043306R9999 220
9 13 3 right 468 2198 × 898 × 349 3/9SF302 2CPX043308R9999 278
Standing housing IP44 ,, depth 349 mm
8 12 1 right 144 2048 × 398 × 349 1/8SF303 2CPX043391R9999 154
8 12 2 right 288 2048 × 648 × 349 2/8SF303 2CPX043392R9999 208
8 12 3 right 432 2048 × 898 × 349 3/8SF303 2CPX043393R9999 261
9 13 1 right 156 2198 × 398 × 349 1/9SF303 2CPX043394R9999 165
9 13 2 right 312 2198 × 648 × 349 2/9SF303 2CPX043395R9999 222
9 13 3 right 468 2198 × 898 × 349 3/9SF303 2CPX043396R9999 280
Important note
A cooling shutter is included for F90 fire resistance.
