Consumer units
MISTRAL65 – Ordering details with terminals IP65

MISTRAL65 – Order codes
N° of Dimensions
modules W x H x D
Description [18 mm] GWT [mm] Order code Type code Packaging
Consumer units MISTRAL65 wall - 48 modules
Opaque door 48M 52SM 48 650 320x735x155 1SLM006501A1107 65P12X41A 1/1
Transparent door 48M 52SM 48 650 320x735x155 1SLM006501A1207 65P12X42A 1/1

48 modules
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9 10 11

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9 10 11
Consumer units MISTRAL65 wall - 54 modules
Opaque door 54M 52SM 54 650 430x600x155 1SLM006501A1108 65P18X31A 1/1
Transparent door 54M 52SM 54 650 430x600x155 1SLM006501A1208 65P18X32A 1/1

54 modules
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22

1 2 3 4 5 6 7 8 9 10 11 1 2 3 4 5 6 7 8 9 10 11

Consumer units MISTRAL65 wall - 72 modules
Opaque door 72M 52SM 72 650 430x735x155 1SLM006501A1109 65P18X41A 1/1
Transparent door 72M 52SM 72 650 430x735x155 1SLM006501A1209 65P18X42A 1/1

72 modules 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22

1 2 3 4 5 6 7 8 9 10 11 1 2 3 4 5 6 7 8 9 10 11
