Consumer units
MISTRAL65 – Ordering details with terminals IP65

MISTRAL65 – Order codes
N° of Dimensions
modules W x H x D
Description [18 mm] GWT [mm] Order code Type code Packaging
Consumer units MISTRAL65 wall - 24 modules
Opaque door 24M 42SM 24 650 320x435x155 1SLM006502A1104 65P12X21A 1/4
24 modules Transparent door 24M 42SM 24 650 320x435x155 1SLM006502A1204 65P12X22A 1/4

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9
Consumer units MISTRAL65 wall - 36 modules
Opaque door 36M2F 52SM 36 650 430x435x155 1SLM006501A1105 65P18X21A 1/2
Transparent door 36M2F 36 650 430x435x155 1SLM006501A1205 65P18X22A 1/2
36 modules
52SM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22

1 2 3 4 5 6 7 8 9 10 11 1 2 3 4 5 6 7 8 9 10 11

Consumer units MISTRAL65 wall - 36 modules
Opaque door 36M3F 42SM 36 650 320x600x155 1SLM006501A1106 65P12X31A 1/3
Transparent door 36M3F 36 650 320x600x155 1SLM006501A1206 65P12X32A 1/3
42SM

36 modules
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9
