20/54 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Automation boards
Ordering codes - SR2 enclosures

Closing systems
These can replace the standard closures of the external doors.
The inserts are interchangeable and easily replaced by loosening a single nut.
AA8001
Package/
No. of
Description Code pieces
Box Ø 19 mm double tongue and plastic key (spare part) AA8001 1/1
AA8002 Box Ø 19 mm with security insert and Yale type key AA8002 1/1
Box Ø 19 mm with handle and Yale type key AA8003 1/1
Box Ø 19 mm with triangular insert AA5200 1/1
Plastic key for triangular insert AA5200 AA5190 1/1
Ergonomic box complete with double tongue insert EV1008 1/1
(without tongue)
AA8003
Single code Yale insert EV1036 1/1
Ronis 455 insert for EV1037 1/1
3mm Double tongue insert EV1039 1/1

EV1008

Document pocket RAL 7035
Made of plastic, RAL 7035 colour, A4 size. The pocket can be glued inside the blind door with
a width of more than 400 mm, using the adhesives provided.

Package/
No. of
Description Code pieces
Plastic document pocket for A4 EV1075K 1/1

Special Painting Service
Special painting service has to manage with code of enclosure SRN....SPEC ( e.g. SRN4320SPEC
VERNSR + note about color required ). It is necessary specify the color required in the order. Min-
imum order quantity 4 pieces. For any other component or further information, please contact
you local sales network.

Package/
No. of
Description Code pieces
Extra cost for special SR painting VERNSR

Accessories for DIN panel

Hole covering strip RAL7035 colour
Package/
No. of
Description Code pieces
No.10 hole covers W=2000mm, grey AD1086 1/10
No.3 hole covers 24 DIN modules W=600mm AD1088 1/3
No.3 hole covers 36 DIN modules W=800mm AD1089 1/3
20
