20/60 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Automation boards
Ordering codes - SR2 enclosures

Special Drilling Service
The overprice amount depends on the number of individual drilled parts and not on the num-
ber of holes.
D For single part it means: A-door B-plate; C-housing; D-top/bottom part.
Please note that the minimum quantity is 4 pieces with a single code.
C
The price of the special drilling service depends on the number of parts to be drilled and on
A C the amount of enclosures to be drilled.

No. of enclosures
B
Description Code to be drilled
Extra cost for drilling service per individual drilled part (A-B-C-D) FORSR1 4-5-6
Extra cost for drilling service per individual drilled part (A-B-C-D) FORSR2 7-8-9
Extra cost for drilling service per individual drilled part (A-B-C-D) FORSR ≥ 10

Standard size enclosures with special drilling
The special drilling service for standard size enclosures in quantities equal to or greater than
4 units with a single code has to be managed with code SRN ... SPEC + overprice FORSR/
FORSR1/FORSSR2 (see table) equal to the number of enclosures and the number of parts to
be drilled + hole layout to be attached to the order (see on the next page).
Example: Enclosure (4 pcs) with door to be drilled (1 part)

Example: Enclosure (4 pcs) with door and plate to be drilled (1 parts)
SRN4320SPEC 4
FORSR1 4
DRAWINGS TO BE ATTACHED

Example: Enclosure (4 pcs) with door and plate to be drilled (2 parts)
SRN4320SPEC 4
FORSR1 8
DRAWINGS TO BE ATTACHED

Non-standard enclosure sizes, special drilling
Request feasibility of implementation by completing the relevant Form for special
quotations and send it together with the drill layout to the R&D ECS office.
Management is per offer.
If the offer is accepted and after having received it, it will be possible to place the order
with the codes indicated in the offer, that will not be SRN...SPEC, but dummy ones.
Always remember to indicate the offer reference in the order.
