Automation boards
Ordering codes - SRX enclosures

SRX series enclosures with opaque door (internal plate included)
Enclosures with an opaque door, made of AISI 304 stainless steel, usually intended for
producing enclosures for automation, come supplied with the galvanised sheet metal
120° internal plate and do not have cable entry flanges.

Enclosures with opaque door complete with internal mounting plate
Dimensions (mm) Package/
No. of
H W D Code pieces
300 200 150 SRN3215X 1/1
400 SRN3415X 1/1
400 300 150 SRN4315X 1/1
300 200 SRN4320X 1/1
400 SRN4420X 1/1
600 SRN4620X 1/1
500 400 200 SRN5420X 1/1
500 SRN5520X 1/1
600 400 200 SRN6420X 1/1
600 SRN6620X 1/1
600 300 SRN6630X 1/1
700 500 250 SRN7525X 1/1
800 600 200 SRN8620X 1/1
600 300 SRN8630X 1/1
800 SRN8830X 1/1
1000 800 300 SRN10830X 1/1
1200 600 300 SRN12630X 1/1
800 SRN12830X 1/1

SRX series stainless steel enclosures with transparent door
AISI 304 stainless steel enclosures with a glass door can also be used for distribution
configurations. The internal equipment is set up using the relevant kits:
- KD...X (Distribution Kit) consisting of a pair of functional uprights for assembly of the
120°
modular panels made of AISI 304 stainless steel (to be ordered separately) and of any
compensation panels. The modular panels, which can also be installed on the enclosures
with opaque door using the KD kit, are all hinged and have vertical modularity of 185 mm.
The enclosures with see-through door are provided without mounting plate.

Enclosures with transparent door
Dimensions (mm) Package/
No. of
H W D Code pieces
500 400 200 SRN5420VX 1/1
600 400 SRN6420VX 1/1
700 500 250 SRN7525VX 1/1
800 600 SRN8625VX 1/1
1000 800 300 SRN10830VX 1/1
