Connection accessories for starting solutions with Push-in Spring terminals

Connecting links with manual motor starters 03
1SBC101673V0014 The BEA..-4KF insulated 3-pole connecting links are used to connect AF09..K ... AF38..K contactors
with the MS132-K manual motor starters. The BEA..-4KF insulated 3-pole connecting links ensure
the electrical and mechanical connection between the contactor and the associated manual
motor starter.
BEA16-4KF
For 3-pole Manual motor starter Type Order code Pkg Weight
contactors qty (1 pce)
kg
AF09..K ... AF16..K MS132-0.16 … MS132-25 BEA16-4KF 1SBN081325T1000 10 0.052
AF26..K ... AF38..K MS132-0.16 … MS132-32 BEA38-4KF 1SBN082325T2000 10 0.057

PMS38-4

1SBC100128V0014 Connection sets for reversing contactors

AF09..K ... AF16..K BER16-4KF 1SBN081322R1000 1 0.050
AF26..K ... AF38..K BER38-4KF 1SBN082322R1000 1 0.080
BER16-4KF

A1 A1
1 3 5 1 3 5
2 4 6 2 4 6
A2 A2
BER
Reversing connections

Connection sets for star-delta starter
AF09..K ... AF16..K BEY16-4KF 1SBN081323R2000 1 0.055
AF26..K ... AF38..K BEY38-4KF 1SBN082323R2000 1 0.090
1SBC100129V0014

BEY16-4KF
Busbars with Push-in Spring terminals
Suitable for Rated No. of Number Type Order code Pkg Weight
A1 A1 A1
1 3 5 1 3 5 1 3 5 operational manual of lateral qty (1 pce)
2 4 6 2 4 6 2 4 6 current motor auxiliary
A2 A2 A2
A starter contacts
BEY kg
Line-delta-star connection MS132K, 65 2 0 PS1-2-0-65K 1SAM301903R1002 1 0.091
MS132-KT 65 3 0 PS1-3-0-65K 1SAM301903R1003 1 0.116
65 4 0 PS1-4-0-65K 1SAM301903R1004 1 0.140
65 5 0 PS1-5-0-65K 1SAM301903R1005 1 0.165
65 2 1 PS1-2-1-65K 1SAM301903R1012 1 0.094
65 3 1 PS1-3-1-65K 1SAM301903R1013 1 0.123
65 4 1 PS1-4-1-65K 1SAM301903R1014 1 0.151
65 5 1 PS1-5-1-65K 1SAM301903R1015 1 0.178

PS 1-3-1-65K busbar
with Push-in Spring terminals
