carat®
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

F duct-jack Communication adapter
for communication adapter for Mini-jacks 3,5mm.
For connection of antenna cables e.g.. for TVs with Suitable for telephone connection unit cover plates
integrated TV-tuner and satellite receiver. 2539-21x and 1766-xxx.
With screw-type terminals. To support 1 or 2 jacks.
For trunk systems, flush-mounted wall boxes and For trunk systems, flush-mounted wall boxes and
underfloor systems. underfloor systems. Without cover plate. Without claws.
Protection class (Device): IP 20 Protection class (Device): IP 20
metal clad 0262-500 2CKA000230A0440 1 white 0264/11-500 2CKA000230A0458 1
grey 0264/13-500 2CKA000230A0460 1
Communication adapter alpine white 0264/12-500 2CKA000230A0459 1
for Cinch-jacks
Suitable for telephone connection unit cover plates
2539-21x and 1766-xxx. Mini-jack 3,5 mm
To support 1 or 2 jacks. for communication adapter
For trunk systems, flush-mounted wall boxes and For the connection of mobile terminal devices such as
underfloor systems. MP3 player (stereo), mobile telephone and smartphones.
Without cover plate. Audio-band 20Hz - 20kHz.
Without claws. With soldering tag. Protection class (Device): IP 20
Protection class (Device): IP 20
chrome gloss 0264-500 2CKA000230A0462 1
white 0263/11-500 2CKA000230A0444 1
grey 0263/13-500 2CKA000230A0446 1
Stereo loudspeaker connection box )
1
alpine white 0263/12-500 2CKA000230A0445 1 With screwless terminals (with screw-type terminals on
the back).
With 4 terminals.
11
Cinch-jacks Cable cross-section max. 10 mm . 2
for communication adapter Polarity is indicated by color.
To link analogue audio devices like audio-receiver, With claw.
amplifier and HiFi-sets. Protection class (Device): IP 20
Audio-band 20Hz - 20kHz.
Marked white: audio , channel left. white 0248/02-101 2CKA000230A0402 10/100
With soldering tag. 1) Suitable for cover telephone unit 1766-xxx and 2539-21x.
Protection class (Device): IP 20
alpine white 0263/04-500 2CKA000230A0451 1 Stereo loudspeaker connection box )
1
With screwless terminals (with screw-type terminals on
the back).
Cinch-jacks
for communication adapter With 4 terminals. 2
To link analogue audio devices like audio-receiver, Cable cross-section max. 10 mm .
amplifier and HiFi-sets. Polarity is indicated by color.
Audio-band 20Hz - 20kHz. With claw.
Marked black: audio , channel left. Protection class (Device): IP 20
With soldering tag. alpine white 0248/04-101-500 2CKA000230A0464 10/100
Protection class (Device): IP 20 1) Suitable for cover telephone unit 1766-xxx and 2539-21x.
black 0263/05-500 2CKA000230A0452 1
Stereo loudspeaker connection box )
1
Cinch-jacks With screwless terminals (with screw-type terminals on
for communication adapter the back). With 4 terminals.
To link analogue audio devices like audio-receiver, Cable cross-section max. 10 mm . 2
amplifier and HiFi-sets. Polarity is indicated by color. With claw.
Audio-band 20Hz - 20kHz. Protection class (Device): IP 20
Marked red: audio , channel left. anthracite 0248/05-101 2CKA000230A0404 10/100
With soldering tag.
Protection class (Device): IP 20 1) Suitable for cover telephone unit 1766-xxx and 2539-21x.
Red 0263/06-500 2CKA000230A0453 1
Cover plate
For Busch-DigitalRadio 8215 U/8216 U.
Cinch-jacks For Busch-Radio iNet 8216 U.
for communication adapter For Busch-Radio BTconnect 8217 U.
For connecting analogue video devices, such as
DVD players, hard disc recorders, video recorders or
receivers.
Marked yellow: audio , channel left. anthracite 8252-81 2CKA008200A0050 10
With soldering tag. ivory white 8252-82 2CKA008200A0051 10
Protection class (Device): IP 20
studio white 8252-84 2CKA008200A0053 10
yellow 0263/07-500 2CKA000230A0454 1
