11/406 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Swing®L
Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Rotary control dimmer insert with switch-on at Rotary control dimmer insert
minimal brightness level 9) with switch-on at minimal brightness level,
With cover plate fastening nut. combined with ON/OFF soft-catch 9) 13)
For also for certain 230 V AC compact fluorescent For 11)
lamps with screw cap (energy saving lamps), designed The switching part of the insert can be combined
for dimming (using leading-edge phase control). with 1g2w or 1g2w/intermediate switches.
min. 60 W, max. 400 W for vacuum and halogen lamps, The dimmed output is independent on the switch.
230 V AC Switch: 6 A; dimmer: min. 60 W/V·A, max. 400 W/V·A,
min. 10 W, max. 80 W for dimmable compact 230 V AC
fluorescent lamps, 230 V AC
6517 U-101-500 6517-0-0018 1
2200 U-503 6514-0-0111 1 9) At ambient temperature higher than 35 °C the load must be reduced by approx.
9) At ambient temperature higher than 35 °C the load must be reduced by approx. 3 % / °C.
3 % / °C. 11) With conventional transformers, take ~20 % transformer losses into account.
13) A neon lamp can be used for orientation illumination
(more detailed information is given in switch range chapters).
Rotary control dimmer insert with ON/OFF soft-catch
9) 13)
For also for certain 230 V AC compact fluorescent Rotary control dimmer insert with ON/OFF soft-catch
9) 13)
lamps with screw cap (energy saving lamps), designed
for dimming (using the leading-edge phase control). Short-circuit and overload electronic protection.
Can be combined with 1g2w or 1g2w/intermediate For 12)
switches (for ON/OFF operation only, brightness Can be combined with 1g2w or 1g2w/intermediate
control is not possible). switches (for ON/OFF operation only, brightness
min. 60 W, max. 600 W for vacuum and halogen lamps, control is not possible).
230 V AC min. 40 W/V·A, max. 420 W/V·A, 230 V AC
min. 10 W, max. 100 W for dimmable compact 6513 U-102 6513-0-0568 1
fluorescent lamps, 230 V AC
11
9) At ambient temperature higher than 35 °C the load must be reduced by approx.
2250 U 6515-0-0704 1 3 % / °C.
11) With conventional transformers, take ~20 % transformer losses into account.
9) At ambient temperature higher than 35 °C the load must be reduced by approx.
12) With electronic transformers, take 5 % transformer losses into account.
3 % / °C. 13) A neon lamp can be used for orientation illumination
13) A neon lamp can be used for orientation illumination (more detailed information is
(more detailed information is given in switch range chapters).
given in switch range chapters).
Electronic potentiometer insert for 1 -10 V electronics
Rotary control dimmer insert with ON/OFF soft-catch ballasts, for rotary control and switch-on at minimal
9) 13)
brightness level
11)
For ; also for certain compact fluorescent lamps For or for LED control via electronic ballast with
for 230 V AC with screw cap (energy saving lamps), 1 - 10 V interface.
designed for dimming (using the leading-edge phase Max. control current: 50 mA DC
control). Potential-free contact for switching the ballast power
Can be combined with 1g2w or 1g2w/intermediate supply. It is recommended to use a relay for more than
switches (for ON/OFF operation only, brightness 5 ballasts.
control is not possible). 4 A (cos φ = 0.9), 3 A (cos φ = 0.5)
min. 20 W/V·A, max. 500 W/V·A, for 230 V or ELV lamps, 700 W/V·A, 230 V AC, 50/60 Hz
230 V AC
min. 5 W, max. 100 W for dimmable compact 2112 U-101 6599-0-2035 1
fluorescent lamps, 230 V AC
2247 U 6512-0-0057 1
9) At ambient temperature higher than 35 °C the load must be reduced by approx.
3 % / °C.
11) With conventional transformers, take ~20 % transformer losses into account.
13) A neon lamp can be used for orientation illumination
(more detailed information is given in switch range chapters).
Rotary control dimmer insert with ON/OFF soft-catch
9) 13)
Short-circuit and overload electronic protection.
Minimum brightness setting option.
For 11)
Can be combined with 1g2w or 1g2w/intermediate
switches (for ON/OFF operation only, brightness
control is not possible).
min. 200 W/V·A, max. 700 W/V·A, 230 V AC
6520 U-500 6520-0-0227 1
9) At ambient temperature higher than 35 °C the load must be reduced by approx.
3 % / °C.
11) With conventional transformers, take ~20 % transformer losses into account.
13) A neon lamp can be used for orientation illumination
(more detailed information is given in switch range chapters).
