Swing®L
Socket outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Double socket outlet with earthing pins, shuttered, Socket outlet with earthing contacts
with turned upper cavity, with surge protection Screw-type terminals.
Optical fault signalling. Fixation via screws or claws.
Screwless terminals. 16 A, 250 V AC
Fixation via screws only.
IP 40
16 A, 230 V AC
white 5518G-A03449 B1 10
white 5593J-C02357 B1 1 ivory 5518G-A03449 C2 10
white / creamy 5593J-C02357 B1C1 1
white / ivory 5593J-C02357 B1C2 1 Double socket outlet with earthing contacts,
white / mocca 5593J-C02357 B1C3 1 shuttered
Screw-type terminals.
white / light
grey 5593J-C02357 B1S1 1 Fixation via screws or claws.
16 A, 250 V AC
white / brick
colour 5593J-C02357 B1R3 1
white 5512J-C03459 B1 10
ivory 5512J-C03459 C2 10
Safety socket with earthing pin,
with built-in RCD, with shutters
Residual working current I : 30 mA Adapter for Profi l 45 inserts
Δn
Type A, AC and pulse current sensitivity For fl ush mounting of any Profi l 45 device
Rated current In: 16 A (see pages 254 - 256) into switch ranges.
Rated frequency: 45-60 Hz For the assembly it is necessary to use
Trip time at 5× I : max. 30 ms cover plate 5016.-A00070 .. and the cover
Δn
Rated short-circuit current: 3000 A frame from the desired switch range. 11
Impulse current resistance: 3,000 A, 8/20 μs
Ambient temperature: -25 ° C to +40 °C 5525U-A00100 5/1
Degree of protection: IP 20
Climatic resistance: in accordance with ČSN EN 61008-1
Connection cross-section: 1.5 to 2.5 mm 2 Socket outlet 45×45 with earthing pin
2
2
Built-in depth: 32 mm Only for 2× 1.5 mm or 2× 2.5 mm conductors.
Additional sockets can be connected to terminals L ', N' 16 A, 250 V AC
they will also be under the control of the current
protector.
Screwless terminals.
16 A, 230 V AC white
(RAL 9010) 5525N-C02347 B 20
white 5526G-A02369 B1 1
carmine
ivory 5526G-A02369 C1 1
(RAL 3003) 5525N-C02347 R1 20
Socket outlet with earthing contacts, shuttered
Screw-type terminals.
Fixation via screws or claws.
16 A, 250 V AC
Screwless terminals.
Fixation via screws or claws.
16 A, 250 V AC
white 5520G-A03457 B1 10/1
ivory 5520G-A03457 C2 10/1
Socket outlet with earthing contacts, shuttered
Screw-type terminals.
Fixation via screws or claws.
16 A, 250 V AC
Screw-type terminals.
Fixation via screws or claws.
16 A, 250 V AC
white 5518G-A03459 B1 10
ivory 5518G-A03459 C2 10
