11/408 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Swing®L
Blind control Socket outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Blind rocker switch mechanism Socket outlet with earthing pin, shuttered
3)
1-gang 1-way switch Screw-type terminals.
10 AX, 250 V AC Fixation via screws or claws.
Screwless terminals. IP 40
Fixation via screws or claws. 16 A, 250 V AC
3557-A89440 20 white 5518G-A02459 B1 10
ivory 5518G-A02459 C2 10
3) A neon lamp or LED cannot be used.
Blind rocker switch mechanism Socket outlet with earthing pin
3)
1-gang 1-way push-switch Screw-type terminals.
10 A, 250 V AC Fixation via screws or claws.
Screwless terminals. 16 A, 250 V AC
Fixation via screws or claws.
3557-A88440 20 white 5518G-A02449 B1 10
3) A neon lamp or LED cannot be used.
ivory 5518G-A02449 C2 10
Blind switch rocker with markings Socket outlet with earthing pin,
For 2g1w blind switch with interlock. shuttered, with labelling field
For 2g1w blind push-switch with interlock. Screw-type terminals.
Fixation via screws or claws.
IP 40
16 A, 250 V AC
11
white 3557G-A00662 B1 20 white 5518G-A02452 B1 10
ivory 3557G-A00662 C2 20 ivory 5518G-A02452 C2 10/1

Double socket outlet with earthing pins,
shuttered, semifl ush-mounted
Screw-type terminals.
Fixation via screws only.
16 A, 250 V AC
5512J-C02259 B1 10

Double socket outlet with earthing pins,
shuttered, with turned upper cavity
Screwless terminals.
Fixation via screws only.
IP 40
16 A, 250 V AC
white 5513J-C02357 B1 10
white / creamy 5513J-C02357 B1C1 10/1
white / ivory 5513J-C02357 B1C2 10/1
white / mocca 5513J-C02357 B1C3 10/1
white / light
grey 5513J-C02357 B1S1 10/1
white / brick
colour 5513J-C02357 B1R3 10/1

Socket outlet with earthing pin,
with surge protection
Optical fault signalling.
Screw-type terminals.
Fixation via screws only.
16 A, 230 V AC
white 5598G-A02349 B1 1
ivory 5598G-A02349 C2 1
