11/407

—
Swing®L
Dimmers Movement detectors

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

DALI Power-potentiometer insert, with rotary control Switch insert for movement detector
and ON/OFF push operation Switching element: relay
For central switching and dimming up to 64 DALI Operating temperature: –10 °C to +55 °C
devices in accordance with EN 62386. Increased 2 300 W for , 1 750 V·A for ,
brightness sensitivity setting at slow rotation. 500 V·A / 64 μF pro
44)
Integrated orientation LED illumination (18 colour For easy connection, terminal N is doubled.
presets or OFF). 3-wire connection, 230 VAC
Short-circuit and overload electronic protection.
DALI cable length: max. 300 m (cores’ cross section 1.5 3299U-A00006 1
to 2.5 mm ). 44) Also for example, for compact 230 V AC lamps (so-called CFL bulbs) or luminaires
2
The brightness level when switched on by brief with LED.
pressing: the same as it was when last used or pre-
selectable. The brightness level when the power supply
is restored after power failure: switched off status or Switch insert for movement detector
pre-selectable (if supported by the DALI device). Switching element: 2 relays (relay 2 switches on about
In active mode the insert serves as a DALI power supply 3 min after relay 1 switches on, independently of
(15.5 V DC / 75 mA) for up to 37 DALI devices (or for up external lighting; relay 2 switches off about 5 min after
to 111 DALI devices with 3 power-potentiometers in relay 1)
parallel connection). Operating temperature: –10 °C to +55 °C
44)
In passive mode the insert behaves as an additional Max. 3 A (cos φ > 0,8)
control unit. One spare fuse is inserted in the fuse box.
Parallel interconnection of power-potentiometers: up 4-wire connection, 230 VAC
to 3 pcs in active mode or up to 5 pcs in passive mode. 3299U-A00005 1
The insert is not suitable for combination with other 44) Also for example, for compact 230 V AC lamps (so-called CFL bulbs) or luminaires
DALI sensors. with LED.
Power consumption: max. 2.5 W
4-wire connection in active mode, 2-wire connection in 11
passive mode 230 V AC, 50/60 Hz Switch insert for movement detector
Switching element: triac
2117/11 U-500 6599-0-2988 1 5 s before switching off the brightness is reduced
Operating temperature: –10 °C to +55 °C
DALI potentiometer insert, with rotary control 40 - 300 W pro
and ON/OFF push operation One spare fuse is inserted in the fuse box.
For central switching and dimming up to 64 DALI 2-wire connection, 230 V AC
devices in accordance with EN 62386. 3299U-A00001 1
Increased brightness sensitivity setting at slow 36) Parallel connection of devices is not allowed. Can not be used for non-ohmic loads
rotation. Integrated orientation LED illumination (18 (control coils, fluorescent relays, LEDs, etc.).
colour presets or OFF). An additional DALI power supply
is needed (e.g. by Tridonic, Philips, Helvar, or the DALI
power-potentiometer 6599-0-2988). Movement detector
Current consumption: 7 - 15 mA Detection angle: approx. 180°
The insert is polarity-reversal proof. Adjustable values (on the back of the cover):
DALI cable length: max. 300 m lighting threshold (1 - 1000 lx); sensitivity;
(cores’ cross section 1.5 to 2.5 mm ) switch-off delay (5 sec - 10 min, or 15 / 30 / 45 /
2
The brightness level when switched on by brief 60 min by pressing integrated button)
pressing: the same as it was when last used Operating temperature: –10 °C to +55 °C
or pre-selectable. Need to be used together with a switch insert for
The brightness level when the power supply is restored movement detector.
after power failure: switched off status or pre-
selectable (if supported by the DALI device). white 3299G-A02180 B1 1
Up to fi ve potentiometers may be connected in parallel. ivory 3299G-A02180 C2 1
The insert is not suitable for combination with other
DALI sensors.
2-wire connection
2117 U-500 6599-0-2987 1

Cover plate for rotary dimmer 16)
With fastening nut.
With two types of button
(for 6514-0-0111 and other devices).

white 3294G-A00125 B1 5
ivory 3294G-A00125 C2 5/1
16) Cover illumination with neon lamp or LED is not possible.
