Zenit
TV socket outlets

Product Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

TV-R/SAT loop-through outlet TV-R/SAT terminal outlet - 2M
TV-R and SAT double outlet - Intermediate. TV-R and SAT double outlet - Final.
Installation as an intermediate outlet in series connected Installation as a terminal outlet connected to a
to each other. tap-off or splitter (without terminal resistor).
Output connectors (C1 / C2): Connection: screw terminal and clamp.
IEC male 9,52 mm. diam. / IEC female 9,52 mm. diam. Output connectors (C1 / C2): IEC male 9,52mm diam. /
Frequency range (I/O / C1 / C2): IEC female 9,52mm diam.
5 - 2.400 MHz / 5 - 2.400 MHz / 5 - 2.400 MHz. Frequency range (I/O / C1 / C2):
Basic loss (FM / TV / SAT): 5 - 2.400 MHz / 5 - 862 MHz / 930 - 2.400 MHz.
10,0±1,0 dB / 10,0±1,0 dB / 12,0±2,0 dB. Basic loss (FM / TV / SAT):
Through loss (FM / TV / SAT): 0,2±0,1 dB / 1,0 ±0,5 dB / 1,2±0,6 dB.
2,5±0,5 / 2,5±0,7 / 3,0±1,0. Isolation (FM / TV / SAT): >45 / >14 / >14.
Directivity (FM / TV / SAT): >20 / >12 / >5. Selectivity (TV-R / SAT): >15 / >15.
Isolation (FM / TV / SAT): >45 / >30 / >28. Return loss (VR / FM / TV / SAT): >25 / >25 / >14 / >10.
Return loss (VR / FM / TV / SAT): >13 / >13 / >12 / >12. DC path (Vdc / mA / Tono):
DC path (Vdc / mA / Tono): 24 max. / 500 max. / 22 KHz - DiSEqC.
24 max. / 500 max. / 22 KHz - DiSEqC.
To be installed with N2250.1 cover plates.
Fitting boxes with 60mm distance between screws White N2251.3 BL 2CLA225130N1101 10
(codes: 1099, 1999 and 1999.2). Silver N2251.3 PL 2CLA225130N1301 10
Anthracite N2251.3 AN 2CLA225130N1801 10
8151.8 2CLA815180A1001 10 Champagne N2251.3 CV 2CLA225130N1901 10
Cover plate for TV-R/SAT - 2M TV-R/SAT final outlet - 2M
Cover plates for outlets with 2 connectors TV-R and SAT double outlet - Final.
codes 8150.3, 8150.7 and 8150.8. Installation as a terminal outlet connected to a series
Covers prepared to fix the frame to the wall. with loop-through outlets.
TV-R and SAT engraved in the front. Connection: screw terminal and clamp. 11
Output connectors (C1 / C2):
IEC male 9,52mm diam. / IEC female 9,52 mm. diam.
Frequency range (I/O / C1 / C2):
White N2250.1 BL 2CLA225010N1101 20 5 - 2.400 MHz / 5 - 2.400 MHz / 5 - 2.400 MHz.
Basic loss (FM / TV / SAT):
Silver N2250.1 PL 2CLA225010N1301 20
3,7±0,3 dB / 4,0±0,5 dB / 5,0±1,2 dB.
Anthracite N2250.1 AN 2CLA225010N1801 20 Isolation (FM / TV / SAT): >20 / >20 / >14.
Return loss (VR / FM / TV / SAT): >16 / >16 / >16 / >9.
Champagne N2250.1 CV 2CLA225010N1901 20 DC path (Vdc / mA / Tono):
24 max. / 500 max. / 22 KHz - DiSEqC.
TV/R/SAT final outlet
TV, R and SAT triple outlet - Final.
Installation as a terminal outlet. White N2251.7 BL 2CLA225170N1101 10
Connection: screw terminal and clamp.
Output connectors (C1 / C2 / C3): IEC male 9,52 mm. Silver N2251.7 PL 2CLA225170N1301 10
diam. / IEC female 9,52 mm. diam. / F female Anthracite N2251.7 AN 2CLA225170N1801 10
Frequency range (I / C1 / C2 / C3):
5 - 2.500 MHz / 5 - 68 & 125 - 862 MHz / Champagne N2251.7 CV 2CLA225170N1901 10
87,5 - 108 MHz / 950 - 2.5000 MHz.
Basic loss (FM / TV / SAT): 2,0 dB / 2,7 dB / 2,3 dB. TV-R/SAT loop-through outlet - 2M
Isolation (FM / TV / SAT): >24,3 / >15 / >15. TV-R and SAT double outlet - Intermediate.
Selectivity (FM / TV / SAT): >15 / >15 / >15. Installation as an intermediate outlet in series connected
Return loss (VR / FM / TV / SAT): >7,6 / >10 / >7,6 / >8,2. to each other.
DC path (Vdc / mA / Tono): Output connectors (C1 / C2):
34 max. / 500 max. / 22 KHz - DiSEqC. IEC male 9,52 mm. diam. / IEC female 9,52 mm. diam.
To be installed with N2252 cover plates. Frequency range (I/O / C1 / C2):
Fitting boxes with 60mm distance between screws 5 - 2.400 MHz / 5 - 2.400 MHz / 5 - 2.400 MHz.
(Codes: 1099, 1999 and 1999.2).
Basic loss (FM / TV / SAT):
10,0±1,0 dB / 10,0±1,0 dB / 12,0±2,0 dB.
8152.7 2CLA815270A1002 10 Through loss (FM / TV / SAT):
2,5±0,5 / 2,5±0,7 / 3,0±1,0.
Directivity (FM / TV / SAT): >20 / >12 / >5.
Cover plate for TV/R/SAT - 2M Isolation (FM / TV / SAT): >45 / >30 / >28.
Cover plates for outlets with 3 connectors Return loss (VR / FM / TV / SAT): >13 / >13 / >12 / >12.
code 8152.7. DC path (Vdc / mA / Tono):
Covers prepared to fix the frame to the wall. 24 max. / 500 max. / 22 KHz - DiSEqC.
TV, R and SAT engraved in the front.
White N2252 BL 2CLA225200N1101 20 White N2251.8 BL 2CLA225180N1101 10
Silver N2252 PL 2CLA225200N1301 20 Silver N2251.8 PL 2CLA225180N1301 10
Anthracite N2252 AN 2CLA225200N1801 20 Anthracite N2251.8 AN 2CLA225180N1801 10
Champagne N2252 CV 2CLA225200N1901 20 Champagne N2251.8 CV 2CLA225180N1901 10
