Zenit
DND / MUR systems

Color Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

LED DND signaling light - 1M Bell push-button with DND/MUR LED indicator - 2M
Rated voltage: 127-230 Vac / 50-60 Hz. Rated voltage: 110 - 250 Vac
Lamp: white LED. Rated current: 10A
Luminous flux: > 2 lumen at 1 meter. Red Do Not Disturb and green Make Up Room LED
Red diffuser. signaling included.
Do Not Disturb (DND) symbol. Push-button with bell symbol.
To be controlled with N2244.5 DND/MUR 2-gang To be connected to N2244.4 or N2244.5 DND/MUR room
interlocked switch. module and N2224 or N2224.1 electronic bell or N2119 or
N2219 buzzer.

White N2180.4 BL 2CLA218040N1101 5 White N2280.4 BL 2CLA228040N1101 5
Silver N2180.4 PL 2CLA218040N1301 5 Silver N2280.4 PL 2CLA228040N1301 5
Anthracite N2180.4 AN 2CLA218040N1801 5 Anthracite N2280.4 AN 2CLA228040N1801 5
Champagne N2180.4 CV 2CLA218040N1901 5 Champagne N2280.4 CV 2CLA228040N1901 5
LED MUR signaling light - 1M DND/MUR 2-gang switch - 2M
Rated voltage: 127-230 Vac / 50-60 Hz. Rated voltage: 110 - 250 Vac.
Lamp: white LED. Rated current: 16A.
Luminous flux: > 2 lumen at 1 meter. Non interlocked gangs.
Green diffuser. Gang 1: Make Up Room (MUR) green symbol and indicator
Make Up Room (MUR) symbol. LED lamp.
To be controlled with N2244.5 DND/MUR 2-gang Gang 2: Do Not Disturb (DND) red symbol and indicator
interlocked switch. LED lamp.
To be connected to N2280.4 corridor module.
11
White N2180.5 BL 2CLA218050N1101 5 White N2244.4 BL 2CLA224440N1101 5
Silver N2180.5 PL 2CLA218050N1301 5 Silver N2244.4 PL 2CLA224440N1301 5
Anthracite N2180.5 AN 2CLA218050N1801 5 Anthracite N2244.4 AN 2CLA224440N1801 5
Champagne N2180.5 CV 2CLA218050N1901 5 Champagne N2244.4 CV 2CLA224440N1901 5

DND/MUR 2-gang interlocked switch - 2M
Rated voltage: 110 - 250 Vac.
Rated current: 16 AX.
Interlocked gangs.
Gang 1: Make Up Room (MUR) green symbol.
Gang 2: Do Not Disturb (DND) red symbol.
To control N2180.4 & N2180.5 DND/MUR signaling lights or
N2280.4 DND/MUR push-button.

White N2244.5 BL 2CLA224450N1101 5
Silver N2244.5 PL 2CLA224450N1301 5
Anthracite N2244.5 AN 2CLA224450N1801 5
Champagne N2244.5 CV 2CLA224450N1901 5
