Zenit - Sound system
Multiroom Bluetooth system FM radio with alarm

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Multiroom sound module FM-radio and alarm module - 2M
Rated voltage: 127-230 Vac ± 15%; 50-60 Hz. Rated voltage: 230 Vac ± 15%; 50-60 Hz.
Max. consumption: 200 mA. Max. consumption: 100 mA.
Stand-by consumption: 0,3W. Stand-by consumption: 0,2W.
Amplifier power: 6+6 W; <1% distortion (4 Ω). Amplifier power: 2+2 W; <1% distortion (16 Ω).
Speaker impedance: 4 Ω (2+2 W audio). Speaker impedance: 16 Ω (2+2 W audio).
FM radio digital tuner with RDS. FM radio digital tuner with RDS.
Alarm clock with buzzer, radio types and snooze function. Alarm clock with buzzer, radio types and snooze function.
Bluetooth receiver: Bluetooth® v2.1 2.4GHz IEEE 802.15.1. Optional: auxiliary module 9368.3 for I/O (1 mini-jack
Multiroom function available (1 master device and up to 14 stereo input & 1 mini-jack stereo output), USB connection
slave devices). and Bluetooth receiver functions.
Remote control using code 9368.2 (ZigBee 2.4GHz IEEE Mounting grid delivered with the cover plate (without
802.15.4). fixing claws).
Optional: auxiliary module 9368.3 for I/O (1 mini-jack Cover plate code: N2268.
stereo input & 1 mini-jack stereo output) and USB
connection functions.

9368.1 2CLA936810A1001 1 9368 2CLA936800A1001 1

Remote control for multiroom sound module - 2M FM-radio and alarm module - 2M
Rated voltage: 127-230 Vac ± 15%; 50-60 Hz. Rated voltage: 127 Vac ± 15%; 50-60 Hz.
Max. consumption: 15 mA. Max. consumption: 100 mA.
Stand-by consumption: 0,5W. Stand-by consumption: 0,2W.
To control 9368.1 module (1 remote control for each Amplifier power: 2+2 W; <1% distortion (16 Ω).
module). Speaker impedance: 16 Ω (2+2 W audio).
11
Wireless connection between moles 9368.1 and 9368.2 FM radio digital tuner with RDS.
(ZigBee 2.4GHz IEEE 802.15.4). Alarm clock with buzzer, radio types and snooze function.
Optional: auxiliary module 9368.3 for I/O (1 mini-jack Optional: auxiliary module 9368.3 for I/O (1 mini-jack
stereo input & 1 mini-jack stereo output) and USB stereo input & 1 mini-jack stereo output), USB connection
connection functions. In case of using 9368.3 module, the and Bluetooth receiver functions.
connection between modules 9368.1 and 9368.2 must be Mounting grid delivered with the cover plate (without
wired (3 wires). fixing claws).
Mounting grid delivered with the cover plate (without Cover plate code: N2268.
fixing claws).
Cover plate code: N2268.

9368.2 2CLA936820A1001 1 9368.7 2CLA936870A1001 1

Cover plate for radio/remote control modules Cover plate for radio/remote control modules
Cover plate for FM-radio module and for remote control Cover plate for FM-radio module and for remote control
module code: 9368, 9368.2 & 9368.7. module code: 9368, 9368.2 & 9368.7.

White N2268 BL 2CLA226800N1101 1 White N2268 BL 2CLA226800N1101 1
Silver N2268 PL 2CLA226800N1301 1 Silver N2268 PL 2CLA226800N1301 1
Anthracite N2268 AN 2CLA226800N1801 1 Anthracite N2268 AN 2CLA226800N1801 1
Champagne N2268 CV 2CLA226800N1901 1 Champagne N2268 CV 2CLA226800N1901 1
