Page 1552 - Din prodcuts 2020

11/446 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Zenit
Signaling and lighting systems

Color Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

LED white signaling light - 1M LED red signaling light - 1M
Rated voltage: 127-230 Vac / 50-60 Hz. Rated voltage: 127-230 Vac / 50-60 Hz.
Lamp: white LED. Lamp: white LED.
Luminous flux: > 2 lumen at 1 meter. Luminous flux: > 2 lumen at 1 meter.
White diffuser. Red diffuser.

White N2180 BL 2CLA218000N1101 5 Red N2180 RJ 2CLA218000N1601 5
LED warm white signaling light - 1M LED red signaling light - 1M
Rated voltage: 127-230 Vac / 50-60 Hz. Rated voltage: 127-230 Vac / 50-60 Hz.
Lamp: white LED. 2.700 Kelvin. Lamp: white LED.
Low luminous flux: < 0,5 lumen at 0,3 meter. Luminous flux: > 2 lumen at 1 meter.
White diffuser. Green diffuser.

White N2180.1 BL 2CLA218010N1101 5 Green N2180 VD 2CLA218000N1801 5

LED signaling light - 2M
Rated voltage: 127-230 Vac / 50-60 Hz.
Lamp: white LED.
Luminous flux: > 2 lumen at 1 meter.
White diffuser.

White N2280 BL 2CLA228000N1101 1
11
LED DND/MUR signaling light - 2M
Rated voltage: 127-230 Vac / 50-60 Hz.
Lamp: red/green LED.
Luminous flux: > 2 lumen at 1 meter.
White diffuser.

White N2280.2 RJ/VD 2CLA228020N1101 1

Beacon LED light - 2M
Rated voltage: 230 Vac / 50 Hz.
Lamp: white LED.
Luminous flux: > 2 lumen at 1 meter.
White diffuser.
Autonomy: 3 hours (1 hour at maximum illumination 2
hours with lower illumination).
Battery: Ni-MH (estimated lifetime: 4 years).
White N2281 BL 2CLA228100N1101 1

Labels for signaling / beacon lights - 2M
Labels with symbols for signaling and beacon lights code:
N2280, N2280.2 & N2281.
Symbols: “WC men”, “WC women”, “No smoking”,
EN “Direction”, “WC handic.”, “WC”, “Salida” and no symbol
BLANCO
label.
N2281.1 2CLA228110N1001 5
