Zenit - ABB-free@home®
Sensor & blind actuators Motion sensor & actuators

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

free@home Sensor/Blind actuator 1/1-gang - 2M free@home 180° motion sensor - 2M
For controlling blind and awning motors. With integrated With select lens for detection with animal access. For
blind actuator. Blind function is available pre-configured. automatic switching of ABB-free@home® actuators
To be used with ABB-free@home® 2 fold push buttons. dependent on movement and brightness. To be used
Outputs: 1× Change-over contacts/normally open with ABB-free@home® Zenit cover plates for movement
contact, potential-bound. detector.
Rated power: 920 VA. Detection range: frontal 6 m, lateral 3 m.
Rated current: 4 A. Detection angle: 180°.
Suitable for: Operating mode blind. Brightness limit value: 1 – 500 lux.
Protection class of device: IP 20. Protection class of device: IP 20.
Mounting depth: 31,5 mm. Mounting depth: 14.1 mm.
To be installed with SR-2-N2 cover plates. To be installed with CP-MD-N2 cover plates.
MD-F-1.0.PB.1 2CKA006220A0229 1

SBA-F-1.1.PB.1 2CKA006220A0237 1
free@home 180° motion sensor/actuator - 2M
With select lens for detection with animal access.
free@home Sensor/Blind actuator 2/1-gang - 2M Including an integrated actuator for switching 230 V~
For controlling blind and awning motors. With integrated devices. To be used with ABB-free@home® Zenit cover
blind actuator. Blind function is available pre-configured. plates for movement detector.
To be used with ABB-free@home® 4 fold push buttons. Outputs: 1× normally open contact, potential free.
Outputs: 1× Change-over contacts/normally open Suitable for: resistive.
contact, potential-bound. Rated current: 10 A.
Rated power: 920 VA. Rated power: 2300 W.
Rated current: 4 A. Suitable for: capacitive.
Suitable for: Operating mode blind. Rated current: 10 AX. 11
Protection class of device: IP 20. Detection range: frontal 6 m, lateral 3 m.
Mounting depth: 31,5 mm. Detection angle: 180°.
To be installed with SR-4-N2 cover plates. Brightness limit value: 1 – 500 lux.
Protection class of device: IP 20.
Mounting depth: 31.5 mm.
To be installed with CP-MD-N2 cover plates.
SBA-F-2.1.PB.1 2CKA006220A0238 1
MSA-F.1.1.PB.1 2CKA006220A0231 1
Sensor & dimmer actuators

free@home Room temperature controller - 2M
Room temperature control function for controlling
commercially available valve drives or analogue valve
drives (continuous controllers).
With display of set-value temperature. Only to be used
with ABB-free@home® Zenit cover plates for room
thermostat.
Display elements: LCD Display showing operation modes.
Protection class of device: IP 20.
Mounting depth: 17,9 mm.
To be installed with CP-RTC-N2 or CP-RTC-FC-N2 cover
plates.
RTC-F-1.PB 2CKA006220A0276 1
