11/660 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Movement detector
Busch-Watchdog, surface-mounted

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-Watchdog 220 MasterLINE select ) Busch-Watchdog 220 MasterLINE premium ) )
1
2
Electronic movement detector for detecting thermal incl. IR remote control
motion. Electronic movement detector for detecting thermal
Remote operation via IR remote control 6841-101. motion.
Remote configurable via IR service remote control For potential-free operation.
6842-101. With 2-zone detection and 2 separate switching
With display for detection and operation mode. outputs.
With high-quality lens for optimum detection. With connectable, movement-independent twilight
Detection sensitivity adjustable via IR service remote switching operation.
control. Remote control possible via IR remote control 6841-101
Surveillance density: 28 sectors with 112 switching (included in scope of delivery).
segments. Remote configurable via IR service remote control
With integrated dismantling protection. 6842-101.
All functions controlled by microprocessor. With display for detection and operation mode.
Continuous light (4 hours), light deactivation (4 hours) With ground and rear-field detection.
and presence simulation can be activated via IR remote With high-quality lens for optimum detection.
control. Detection sensitivity adjustable via IR service remote
Reading in the current brightness value as switching control.
threshold via remote control. Surveillance density: 91 sectors with 364 switching
With automatic range stabilization. segments.
With automatic interference suppression. With integrated dismantling protection.
With automatic dazzle-proofing. All functions controlled by microprocessor.
With brightness-independent test mode for evaluating Continuous light (4 hours), light deactivation (4 hours)
the detection zone. and presence simulation can be activated via IR remote
Individual adjustment of detection range via enclosed control.
protective foil which can be cut to size. Reading in the current brightness value as switching
Additional possibility for switch-on via normally open threshold via remote control.
11
push-button switch. With automatic range stabilization.
Switch-off delay: 10 sec to 30 min or short-time pulse With automatic interference suppression.
1 sec adjustable. With automatic dazzle-proofing.
Rated voltage: 230 V~, +10 % / -10 % With brightness-independent test mode for evaluating
Rated frequency: 50 Hz - 60 Hz the detection zone.
Outputs: 1x Normally open contact, potential-bound Individual adjustment of detection range via enclosed
Suitable for: ohmic, capacitive and inductive loads protective foil which can be cut to size.
Rated current: 16 AX, cos φ 0.6 Additional possibility for switch-on via normally open
Rated power: 3680 W/VA push-button switch.
Detection range: frontal: 16 m, lateral: 16 m Switch-off delay: 10 sec to 30 min or short-time pulse
Detection angle: 220 ° 1 sec adjustable.
Brightness limit value: 0.5 Lux - 300 Lux , Daytime Rated voltage: 230 V~, +10 % / -10 %
operation Rated frequency: 50 Hz - 60 Hz
Mounting height: 2.5 m - 8 m alternative: 1.1 m Outputs: 1x Normally open contact, potential-bound
Protection class (Device): IP 55 Suitable for: ohmic, capacitive and inductive loads
Temperature range (Device): -25 °C to 55 °C Rated current: 10 AX, cos φ 0.6
Dimensions: (L x W x D): 115 mm x 125 mm x 141 mm Rated power: 2300 W/VA
Control/Signal outputs: 1, Normally open contact,

potential free
white 6847 AGS-204-500 2CKA006800A2537 1 Rated power: 0.12 - 2300 W/VA
Detection range: frontal: 16 m, lateral: 16 m
1) In combination with a relay/contactor, an RC suppressor 6899 has to be used.
Detection range 2: frontal: 1 m, lateral: 1 m
Detection angle: 220 °
Brightness limit value: 0.5 Lux - 300 Lux , Daytime
operation
Mounting height: 2.5 m
Protection class (Device): IP 55
Temperature range (Device): -25 °C to 55 °C
Dimensions: (L x W x D): 115 mm x 125 mm x 141 mm

brown 6848 AGM-201-500 2CKA006800A2581 1
white 6848 AGM-204-500 2CKA006800A2578 1
silver metallic 6848 AGM-208-500 2CKA006800A2579 1
anthracite 6848 AGM-35-500 2CKA006800A2580 1
1) In combination with a relay/contactor, an RC suppressor 6899 has to be used.
2) For the activation of additional functions (twilight switch/floating/2-zone
operation), the IR service remote control 6842-101 is required.
