11/662 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Movement detector
Busch-Watchdog, surface-mounted

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Watchdog 90 ProfessionalLINE ) Busch-Watchdog 220 ProfessionalLINE )
1
1
Electronic movement detector for detecting thermal without IR remote control
motion. Electronic movement detector for detecting thermal
With display for detection and operation mode. motion.
With ground and rear-field detection. With display for detection and operation mode.
With planar compensation: +/- 30°. With ground and rear-field detection.
With high-quality lens for optimum detection. With planar compensation: +/- 30°.
Surveillance density: 50 sectors with 200 switching With high-quality lens for optimum detection.
segments. Detection sensitivity selectable in 3 steps.
With brightness-independent test mode for evaluating Surveillance density: 84 sectors with 336 switching
the detection zone. segments.
Additional possibility for switch-on via normally open All functions controlled by microprocessor.
push-button switch. Always-On (4 hours) and Presencesimulation can be
Switch-off delay option: 1 / 3 or 5 min. activated via IR-remote control.
Rated voltage: 230 V~, +10 % / -10 % With automatic range stabilization.
Rated frequency: 50 Hz - 60 Hz With automatic interference suppression.
Outputs: 1x Normally open contact, potential-bound With automatic dazzle-proofing.
Suitable for: ohmic, capacitive and inductive loads With brightness-independent test mode for evaluating
Rated current: 16 AX, cos φ 0.6 the detection zone.
Rated power: 3680 W/VA Additional possibility for switch-on via normally open
Detection range: frontal: 12 m, lateral: 6 m push-button switch.
Detection angle: 90 ° Switch-off delay: 10 sec to 30 min or short-time pulse
Brightness limit value: 3 Lux / 15 lux / daytime operation 1 sec adjustable.
Mounting height: 2.5 m Rated voltage: 230 V~, +10 % / -10 %
Protection class (Device): IP 55 Rated frequency: 50 Hz - 60 Hz
Temperature range (Device): -25 °C to 55 °C Outputs: 1x Normally open contact, potential-bound
Dimensions: (L x W x D): 97 mm x 97 mm x 159 mm Suitable for: ohmic, capacitive and inductive loads
11
Rated current: 16 AX, cos φ 0.6

Rated power: 3680 W/VA
brown 6853 AGM-201 2CKA006800A2318 1 Detection range: frontal: 16 m, lateral: 16 m
alpine white 6853 AGM-204-500 2CKA006800A2321 1/10 Detection angle: 220 °
Brightness limit value: 0.5 Lux - 300 Lux , Daytime
anthracite 6853 AGM-35-500 2CKA006800A2322 1
operation
1) In combination with a relay/contactor, an RC suppressor 6899 has to be used.
Mounting height: 2.5 m
Protection class (Device): IP 55
Temperature range (Device): -25 °C to 55 °C
Dimensions: (L x W x D): 97 mm x 97 mm x 159 mm

alpine white 6845/11AGM- 2CKA006800A2334 1/10
204-500
brown 6845/11AGM-201-5002CKA006800A2335 1
anthracite 6845/11 AGM-35-500 2CKA006800A2336 1
1) In combination with a relay/contactor, an RC suppressor 6899 has to be used.
