Movement detector
Presence detector

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Watchdog Presence tech BasicLINE ) ) Busch-Watchdog Presence tech BasicLINE
2
1
1
2
3
For switching lighting systems that depend on Corridor ) ) )
brightness and movement. For switching lighting systems that depend on
Detection range (for installation height of 3 m), circular, brightness and movement.
up to 8 m in diameter. Detection range (for installation height of 2.5 m, circular,
For semiautomatic and fully automatic operation. up to 24 m in diameter).
Additional activation/deactivation possibility through Additional activation/deactivation possibility through
pushbutton input. pushbutton input.
Adaptation of the detection range possible using the Adaptation of the detection range possible using the
included masking elements. included masking elements.
With brightness-independent test mode for evaluating With brightness-independent test mode for evaluating
the detection zone. the detection zone.
With detection display in test mode. With detection display in test mode.
Mounting possibility in combination with built-in With automatic motion detection.
installation boxes and device sockets. With automatic sensitivity adaptation.
Ceiling installation using integrated spring bracket. Mounting possibility in combination with built-in
Adjustment elements accessible on the front side. installation boxes and device sockets.
Low mounting height (31 mm) Ceiling installation using included dust protection
Surveillance density: 32 sectors with 128 switching socket.
segments. Adjustment elements accessible on the front side.
Switch-off delay: approx. 5 sec - 30 min or short-time Surveillance density: 215 sectors with 860 switching
pulse adjustable. segments.
Rated voltage: 230 V~, +10 % / -10 % Switch-off delay: approx. 10 sec - 30 min or short-time
Rated frequency: 50 Hz - 60 Hz pulse adjustable.
Outputs: 1x Normally open contact, potential-bound Remote control possible via IR service remote control
Suitable for: 230 V incandescent lamps 6843.
Rated power: 2000 W Use outdoors possible due to combination with surface- 11
Suitable for: Energy-saving bulbs mounted housing 6888.
Rated power: 7 - 400 W Rated voltage: 230 V~, +10 % / -10 %
Suitable for: Fluorescent lamps Rated frequency: 50 Hz - 60 Hz
Rated current: 4 AX, cos φ 0.5 Outputs: 1x Normally open contact, potential-bound
Rated power: 1000 W/VA Suitable for: 230 V incandescent lamps
Detection angle: 360 ° Rated power: 2000 W
Brightness limit value: 10 Lux - 2000 Lux Suitable for: Energy-saving bulbs
Mounting height: 2 m - 4 m Rated power: 7 - 400 W
Protection class (Device): IP 40 Suitable for: Fluorescent lamps
Temperature range (Device): 0 °C to 45 °C Rated current: 4 AX, cos φ 0.5
Dimensions: (L x W x D): 111 mm x 111 mm x 59 mm Rated power: 1000 W/VA
Mounting depth: 41 mm60669-2-1 Detection angle: 360 °
Brightness limit value: 10 Lux - 2000 Lux

Mounting height: 2 m - 3 m
alpine white 6814 U-500 2CKA006800A2518 1/24 Protection class (Device): IP 40
Temperature range (Device): -20 °C to 45 °C
1) The detection range with a central approach is reduced.
Dimensions: (L x W x D): 110 mm x 110 mm x 70 mm
2) In combination with a relay/contactor, an RC suppressor 6899 has to be used.
Mounting depth: 48 mmIEC 60669-2-1

alpine white 6818 U-500 2CKA006800A2519 1/18
1) The maximum detection range depends on the mounting site and ambient
conditions.
2) The detection range with a central approach is reduced.
3) In combination with a relay/contactor, an RC suppressor 6899 has to be used.
Surface-mounting box
For Busch-Watchdog Presence tech BasicLINE Corridor
6818 U.
For surface mounting and increase of the protection
type.
Protection class (Device): IP 54
Temperature range (Device): -20 °C to 45 °C
Dimensions: (L x W x D): 106 mm x 106 mm x 26 mm
alpine white 6888 2CKA006899A2305 1/90
