11/661

—
Movement detector
Busch-Watchdog, surface-mounted

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-Watchdog 280 MasterLINE ) Busch-Watchdog 220 WaveLINE ) ) )
1
3
2
incl. IR remote control Wireless movement detector for detecting thermal
Electronic movement detector for detecting thermal motion.
motion. With display for detection and status indication.
Remote control possible via IR remote control 6841-101 With ground and rear-field detection.
(included in scope of delivery). With high-quality lens for optimum detection.
Remote configurable via IR service remote control Surveillance density: 84 sectors with 336 switching
6842-101. segments.
With display for detection and operation mode. With integrated dismantling protection.
With ground and rear-field detection. All functions controlled by microprocessor.
With high-quality lens for optimum detection. With automatic range stabilization.
Detection sensitivity adjustable via IR service remote With automatic interference suppression.
control. With automatic dazzle-proofing.
Surveillance density: 110 sectors with 440 switching With automatic battery monitoring.
segments. Battery service life: typically 5 years, therefore
With integrated dismantling protection. practically maintenance-free.
All functions controlled by microprocessor. With brightness-independent test mode for evaluating
Always-On (4 hours) and Presencesimulation can be the detection zone.
activated via IR-remote control. Individual adjustment of detection range via enclosed
Reading in the current brightness value as switching protective foil which can be cut to size.
threshold via remote control. Combinable with switch actuator WaveLINE, 1gang, with
With automatic range stabilization. extension unit 6701-101.
With automatic interference suppression. Compatible with WaveLINE KNX gateway TP-RF 6770.
With automatic dazzle-proofing. For standalone and group operation.
With brightness-independent test mode for evaluating Switch-off delay: 3 min. (single mode), individually
the detection zone. adjustable at actuator (group mode).
Individual adjustment of detection range via enclosed Send frequency: 868 MHz. 11
protective foil which can be cut to size. Free-field range: approx. 100 m.
Additional possibility for switch-on via normally open Rated voltage: 4.5 V-
push-button switch. Detection range: frontal: 16 m, lateral: 16 m
Switch-off delay: 10 sec to 30 min or short-time pulse Detection angle: 220 °
1 sec adjustable. Brightness limit value: 0.5 Lux - 300 Lux , Daytime
Rated voltage: 230 V~, +10 % / -10 % operation
Rated frequency: 50 Hz - 60 Hz Mounting height: 2.5 m
Outputs: 1x Normally open contact, potential-bound Protection class (Device): IP 55
Suitable for: ohmic, capacitive and inductive loads Temperature range (Device): -25 °C to 55 °C
Rated current: 16 AX, cos φ 0.6 Dimensions: (L x W x D): 115 mm x 125 mm x 141 mm
Rated power: 3680 W/VA brown 6747 AGM-201-500 2CKA006700A0038 1
Detection range: frontal: 16 m, lateral: 16 m
Detection angle: 280 ° alpine white 6747 AGM-204-500 2CKA006700A0035 1
Brightness limit value: 0.5 Lux - 300 Lux , Daytime silver metallic 6747 AGM-208-500 2CKA006700A0036 1
operation
Mounting height: 2.5 m anthracite 6747 AGM-35-500 2CKA006700A0037 1
Protection class (Device): IP 55 1) Battery included in delivery.
Temperature range (Device): -25 °C to 55 °C 2) Battery type: Lithium batteries 1250 mAh (L92 AAA 1.5 V).
Dimensions: (L x W x D): 115 mm x 125 mm x 141 mm 3) Cannot be comnined with ceiling/corner adapter 6868-...

brown 6867 AGM-201-500 2CKA006800A2557 1
white 6867 AGM-204-500 2CKA006800A2554 1/10
silver metallic 6867 AGM-208-500 2CKA006800A2555 1
anthracite 6867 AGM-35-500 2CKA006800A2556 1
1) In combination with a relay/contactor, an RC suppressor 6899 has to be used.
