11/675

—
Movement detector
Presence detector

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Presence detector mini premium KNX ) ) Busch-Presence detector KNX ) 1
1
2
8 meters 12 meters
Detection range (for mounting height 2.5 m, 3 m and 4 Detection range (for mounting height 2.5 m, 3 m and 4
m): circular. m): circular.
Seated persons Ø: max. 5 m, max. 6.5 m and max. 9 m. Seated persons Ø: max. 8 m, max. 10 m and max. 14 m.
Walking persons Ø: max. 6.5 m, max. 8 m and max. 10.5 m. Walking persons Ø: max. 10 m, max. 12 m and max. 16 m.
Visible height 16 mm. Visible height 23 mm.
With 4 channels. With 2 channels.
For dimming/brightness of the rules to a defined value Targeted for connection and disconnection of lights
in a designated collection area. bands depending on the room brightness.
HVAC function for controlling heating and/or cooling Regulation in response to the movement possible.
systems and ventilation systems in the designated Using the device as presence and/or movement
collection area. detectors.
Detectors application with 2 power off stages. Detectors application with 2 power off stages.
Detectors application with integrated monitoring Detectors application with integrated monitoring
function. function.
Constant light controller with up to two independent Constant light switch with up to two independent
channels. channels.
Constant light controller with max. 2 outputs for Constant light switch with max. 2 outputs for
dimming daylight control/rules of two rooflights in the brightness-dependent switching of two light bands in
room. the area.
Integrated object room temperature controller. With integrated KNX bus coupler.
10 freely programmable IR channels (blue and/or white) Suitable for false ceilings with a board thickness from
Incl. 5 logic channels (logic gates, gates, delay and 9 to 25 mm.
staircase lighting) Hole size: Ø 68 mm.
Evaluation via internal brightness sensor. Suitable for surface mounting installation.
Weighting of up to 2 external brightness values and the Cannot be installed in British Standard or VDE 11

internal brightness sensor possible. flushmounted box.
The programming button can be activated with the IR Recommendation: Installation housing from Kaiser
transmitter 6010-25 (-500). HaloX-O (Art.no. 1290-40) with corresponding cover
With integrated KNX bus coupler. plates (1290-47 or 1290-85 for fair faced concrete) or
Suitable for false ceilings with a board thickness from IBTronic H120-68 from Spelsberg.
9 to 25 mm. Connections:
Hole size: Ø 68 mm. KNX-line: Bus connection terminal
Suitable for surface mounting installation. Brightness limit value: 1 Lux - 1000 Lux
Cannot be installed in British Standard or VDE Mounting height: 2 m - 4 m
flushmounted box. Protection class (Device): IP 20
Recommendation: Installation housing from Kaiser Temperature range (Device): -5 °C to 45 °C
HaloX-O (Art.no. 1290-40) with corresponding cover Dimensions: (L x W x D): 91 mm x 91 mm x 45 mm
plates (1290-47 or 1290-85 for fair faced concrete) or Mounting depth: 22 mm
IBTronic H120-68 from Spelsberg. aluminium 6131/30-183-500 2CKA006132A0347 1
Connections: silver
KNX-line: Bus connection terminal
Brightness limit value: 1 Lux - 1000 Lux studio white 6131/30-24-500 2CKA006132A0346 1
Mounting height: 2 m - 4 m matt
Protection class (Device): IP 20 1) For software and description please check the current Online-Catalogue.
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 80 mm x 80 mm x 45 mm
Mounting depth: 29 mm
aluminium 6131/21-183-500 2CKA006132A0345 1
silver
studio white 6131/21-24-500 2CKA006132A0344 1
matt
1) For software and description please check the current Online-Catalogue.
2) HVAC = Heating/ ventilation/air-conditioning
