ABB i-bus® KNX
Lighting Control – DALI

Gateways
DG/S 1.64.1.1 DG/S 2.64.1.1 DG/S 8.1
General
100 – 240 V AC 100 – 240 V AC 100 – 240 V AC
Supply voltage (85...265 V AC; (85...265 V AC; (85...265 V AC;
110...240 V DC) 110...240 V DC) 110...240 V DC)
Type of installation DIN-Rail DIN-Rail DIN-Rail
Module width (space unit) 4 4 6
Number of outputs 1 2 8
Light sensor inputs – – –
Degree of protection IP20 IP20 IP20
Integrated power supply   
Number of DALI participants 64 2 x 64 8 x 16
Broadcast control   
Number of group control 16 2 x 16 –
Individual control 64 2 x 64 –
Self-contained emergency lighting, IEC 62 386-202   –
DT8 lighting (Tunable White, Tc), IEC 62 386-209 – – –
Manual operation   
Supports long-frames – – –
DALI firmware update via KNX – – –
Functions
Enable/disable DALI address assignment   –
Switching, dimming, set brightness   
Human Centric Lighting (HCL) – – –
Dim2Warm – – –
Individual set/dimming colour temperature per group/ – – –
ballast
Tunable White Presets – – –
Operating hours – – –
Standby shutdown – – –
Slave   
Staircase lighting   
Burn-in   
Scenes, 8 bit call   
Scenes, 1 bit call – –  14
Forced   –
Emergency lighting test   –
Partial failure   –
Constant light control – – –
Reaction on KNX bus voltage failure   
Reaction on KNX voltage recovery   
Reaction on DALI bus voltage failure   
Reaction on DALI voltage recovery   
Power on level   –
Device or lamp fault   
Cyclic monitoring telegram   
DALI telegram rate modifiable   –
Commissioning and diagnostic functions
(ABB i-bus® Tool)
Device assignment   –
Group assignment   –
Fault DALI device   –
Fault lamp   –
Function test (ON/OFF/brightness value)   –
Commissioning constant light control – – –
Test emergency lighting   –
Broadcast on/off – – –
Shows if there are unaddressed DALI participants – – –
—
 = Function is supported
– = Function is not supported
