Automation boards
Components for distribution and mixed applications

In distribution and mixed applications, the Gemini switch- Blank or drilled front panels are applied to protect the
board is designed to be fitted with System pro M modular equipment and these can be hinged onto both sides;
devices and Tmax moulded-case circuit breakers. The frame the cables are housed inside the vertical wiring duct inte-
is the load-bearing element of the configuration: DIN rails, grated in the uprights according to an exclusive ABB patent.
partial modular plates and the special Tmax mounting and Wiring is carried out by pulling out the frame and working
cabling kits are snapped onto the uprights. from the front; the ergonomic grip and the standard feet
All the components can be adjusted to six different depths and snap-on hooks supplied make it easy to insert it inside
with a pitch of 12.5 mm and arranged at heights with stan- the switchboard after the job is finished.
dard installation pitch of 150, 225 and 300 mm and a dis-
tance of 75 mm between the rows.

The DIN rail is supplied with special The upright with the incorporated wir- The depth at which the DIN rail, the
hooks already in position for attaching ing duct is an exclusive ABB patent that modular plates, the kit for fixing the
to the uprights. rationalizes the path of cables inside Tmax circuit breakers and the wiring
the switchboard. duct are positioned can be adjusted
with a simple sliding movement.

The frame can be extracted to make The blank and drilled panels are hinged Fixing hooks and feet allow the frame
20
wiring operations easier at the work- onto both sides; the description of the to be snap-mounted inside the box.
bench. installed components can be kept in
the special compartment protected by
a transparent, hinged flange.
