Automation boards
Ordering codes - SR2 enclosures

Enclosures with glazed door
The enclosures with glazed door are also used for distribution configurations. The internal
equipment is made, alternatively, by selecting the special kits:
• KD... (Distribution Kit) consisting of a pair of functional uprights for assembly of the mod-
ular panels (to be ordered separately) and of any compensation panel.
The modular panels, which can also be installed on the enclosures with blind door with the
help of the KD.. kit itself, are all hinged and have vertical modularity of 185 mm.

Enclosures with glazed door
120° Dimensions (mm) Package/
H W D Code No. of pieces
500 (1) 400 200 SRN5420VK 1/1
400 250 SRN5425VK 1/1
600 400 200 SRN6420VK 1/1
400 250 SRN6425VK 1/1
700 500 200 SRN7520VK 1/1
500 250 SRN7525VK 1/1
800 600 250 SRN8625VK 1/1
600 300 SRN8630VK 1/1
1000 600 250 SRN10625VK 1/1
600 300 SRN10630VK 1/1
800 300 SRN10830VK 1/1
1200 600 300 SRN12630VK 1/1
800 300 SRN12830VK 1/1

(1) The enclosures with height less or egual to 500mm hare only a closing box.
