Automation boards
Ordering codes - SR2 enclosures

Blind counterdoor
The internal counterdoor guarantees IP20 degree of protection. Made of steel sheet
15/10mm thick, galvanized and painted orange peel RAL 7035 colour, complete with the
EV1008 ergonomic box and insert with double tongue.

Blind counterdoor
Dimensions (mm) Package/
No. of
H W Code pieces
500 400 KC5040K 1/1
600 400 KC6040K 1/1
700 500 KC7050K 1/1
EV1008 800 600 KC8060K 1/1
1000 600 KC1060K 1/1
1000 800 KC1080K 1/1
1200 600 KC1260K 1/1
1200 800 KC1280K 1/1

Blind internal mounting plate
Internal galvanised sheet mounting plate 20/10mm thick complete with fixing with small
items provided. Possibility of adjusting the depth with the help of a special spacer kit (to be
ordered separately).

Blind back plate for enclosure
Dimensions (mm) Package/
No. of
H W Code pieces
300 200 PF3020 1/1
300 300 PF3030 1/1
300 400 PF3040 1/1
400 300 PF4030 1/1
400 400 PF4040 1/1
400 600 PF4060 1/1
500 300 PF5030 1/1
500 400 PF5040 1/1
600 400 PF6040 1/1
600 600 PF6060 1/1
700 500 PF7050 1/1
800 600 PF8060 1/1
800 800 PF8080 1/1
1000 600 PF1060 1/1
1000 800 PF1080 1/1
1200 600 PF1260 1/1
1200 800 PF1280 1/1
