Automation boards
Ordering codes - SR2 enclosures

SR2 Enclosures with blind door (internal plate included)
The enclosures with blind door, typically for making automation switchgear, are already
fitted with the internal galvanised sheet mounting plate.

Enclosures with blind door (internal plate included)
120°
Dimensions (mm) Package/
300 H W D Code No. of pieces
400 300 (1) 200 150 SRN3215K 1/1
500
300 150 SRN3315K 1/1
400 150 SRN3415K 1/1
400 (1) 300 150 SRN4315K 1/1
300 200 SRN4320K 1/1
400 200 SRN4420K 1/1
120°
600 200 SRN4620K 1/1
500 (1) 300 200 SRN5320K 1/1
600 400 200 SRN5420K 1/1
700
800 400 250 SRN5425K 1/1
600 400 200 SRN6420K 1/1
400 250 SRN6425K 1/1
TS6009 600 250 SRN6625K 1/1
TS7009 700 500 200 SRN7520K 1/1
TS8009
500 250 SRN7525K 1/1
800 600 250 SRN8625K 1/1
120°
600 300 SRN8630K 1/1
800 300 SRN8830K 1/1
1000* 600 250 SRN10625K 1/1
1000 600 300 SRN10630K 1/1
1200
800 300 SRN10830K 1/1
1200* 600 300 SRN12630K 1/1
800 300 SRN12830K 1/1
(1) The enclosures with height less or egual to 500mm hare only a closing box.
* Plates height 1000 / 1200mm have six mounting points .
