2/18 SACE TMAX XT LOW VOLTAGE MOLDED CASE CIRCUIT-BREAKERS

—

Tmax XT1 – Installation

Installation for plug-in circuit-breaker

Flanges

—
Key
1 Flange for plug-in
circuit-breaker 3p
2 Flange for circuit-
breaker 4p
5 Flange for plug-in
circuit-breaker 3p-4p
with direct motor
operator (MOD)
6 Flange for plug-in
circuit-breaker
3p-4p with direct
rotary handle RHD
7 Optional flange
