11/30 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
carat®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Satellite co-axial outlets Radio/TV/SAT Mounting plate ) )
2
1
3gang dead-end feeder with black insert
Broadband technology 47-2.150 MHz. For MTRJ or 2 modular jack inserts.
SAT connection designed as screwable F-male plug. For systems: Ackermann, AMP / tyco Electronics (Slim
with remote feed via F-bush Line (SL) -SM 2gang/switches: 110Connect Jacks,
For DVB-T and broadband-cable-systems. Toolless Jacks / Standard 110Connect Jacks), Brand-Rex,
For analogue and digital transmission. CombiNet, EFB Electronic, Telena.
With claw. For 2 fiber optic modules of the following types: AMP /
Minimal installation depth, class A. tyco Electronics MTRJ.
Protection class (Device): IP 20 Pitch dimensions: (WxH) approx. 14.8 x 20.4 mm.
Without claws.
0232-101-500 2CKA000230A0463 10/100
Protection class (Device): IP 20
1814-500 2CKA001753A9973 10/100
Terminating resistor 1) Compatibility with other manufacturers not listed is to be checked in accordance
75 Ohm with specified snap-in dimensions.
Protection class (Device): IP 20 2) For further information, please refer on the Internet.
Mounting plate ) )
1
2
with blue insert
0239 2CKA000230A0201 10/100 For 2 modular jack inserts.
For system: ITT Cannon RJ45 Cat. 5 type 808 RJ45
Mounting plate ) ) Mark III.
1
2
with green insert Pitch dimensions: (WxH) approx. 16.0 x 11.0 mm.
For 2 modular jack inserts. Without claws.
For systems: CommScope (AVAYA / AT&T / Lucent Protection class (Device): IP 20
11
Technologies), GigaSPEED, PowerSUM, 360 GS 10E bis 1816 2CKA001710A3100 10/100
MGS 600-BK, M1 BH-xx, MPS 100E-xx. 1) Compatibility with other manufacturers not listed is to be checked in accordance
With R&M adapter R310694 suitable for R&M connection with specified snap-in dimensions.
modules R305111, R305112, R305113 and R305114. 2) For further information, please refer on the Internet.
Pitch dimensions: (WxH) approx. 16.9 x 17.9 mm.
Without claws.
2
1
Protection class (Device): IP 20 Mounting plate ) )
with orange base
1810-500 2CKA001753A9974 10/100 For 2 modular jack inserts.
For system: LexCom 150 and LexCom 250.
1) Compatibility with other manufacturers not listed is to be checked in accordance
with specified snap-in dimensions. Pitch dimensions: (WxH) approx. 15.4 x 15.4 mm.
2) For further information, please refer on the Internet.
Without claws.
Protection class (Device): IP 20
Mounting plate ) ) 1819 2CKA001753A8056 10/100
1
2
with red insert 1) Compatibility with other manufacturers not listed is to be checked in accordance
For 2 modular jack inserts. with specified snap-in dimensions.
Suitable for Art. Nos. 0210, 0211 and 0219-101. 2) For further information, please refer on the Internet.
For systems: AMP / tyco Electronics, BTR, EFB, Krone,
Panduit, Quante, Radiall, Setec, Dr.-Ing. Sieger, Telena,
2
1
Thomas & Betts Mounting plate ) )
For Telegärtner AMJ/UMJ connection modules/ with grey base
couplings. For 2 modular jack inserts.
For 2 fiber optic modules of the following types: For system: Panduit MiniCom (Cu. z.B. TX6 10 Gig
3M-Volition, Krone, mvk. Shielded Jack modules and fiber optic modules.
Pitch dimensions: (WxH) approx. 14.8 x 19.4 mm. Pitch dimensions: (WxH) approx. 15.9 x 18.7 mm.
Without claws. Without claws.
Protection class (Device): IP 20 Protection class (Device): IP 20
1812-500 2CKA001753A9972 10/100 1820 2CKA001753A8057 10/100
1) Compatibility with other manufacturers not listed is to be checked in accordance 1) Compatibility with other manufacturers not listed is to be checked in accordance
with specified snap-in dimensions. with specified snap-in dimensions.
2) For further information, please refer on the Internet. 2) For further information, please refer on the Internet.
Flush-mounted assembly adapter
For the accommodation of one or two universal
modules 0219.
For flush-mounted installation.
Suitable for telephone connection unit cover plates
2539-21x and 1766-xxx.
Protection class (Device): IP 20
0219/12 2CKA000230A0395 1/10
