carat®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Universal data connection box with down-leading Data-connection box, RJ 45, cat. 6a iso, shielded ) 1
outlet ) 2 x outlets, 8/8-pole
1
2 x outlets, 8/8-pole With down-leading outlet and LSA self-cutting clamps.
With down-leading outlet. RJ-45 terminals for networks according to Cat 6A, Class
For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3. EA (10 Gbits/s / 500MHz).
Design according to IEC 60 603-7-2:2007. Equates to cat. 6a, Class EA according to
Screw contacts ISO/IEC 11801:2011-06.
With claw. Terminal marking A and B according to TIA/EIA-568-B.2.
Protection class (Device): IP 20 Typ according to EN 60 603-7-51:2011-01.
Shielding according to DIN EN 55022, Class B.
0215 2CKA000230A0243 10
Up to 500 MHz on all pairs of wires.
Mounting 35 mm deep flush 1gang Suitable for 10-Gigabit Ethernet.
boxes: or Dual Box 3070-2/35 BSDB. Suitable for PoE+ according to IEEE 802.3at, >- 1.000
2gang product 2gang combination with adapter plate contact durability.
combinations: APBS in Dual Box only. Flex cable entries from all sides without buckles.
Earthing of housing via 6,3 mm blade terminal at the
neon indicator: not applicable
back possible.
1) Suitable for cover plate 1803-02-xxx.
Re-embedded proofed.
Suitable for Mix-and-Match operation.
Suitable for RJ 11, RJ 12 und RJ 45.
Data-connection box, RJ 45, cat. 6a iso, shielded ) For data cables with a diameter of 6 -10 mm.
1
1gang For trunk systems, flush-mounted wall boxes and
With down-leading outlet and LSA self-cutting clamps. underfloor systems.
RJ-45 terminals for networks according to Cat 6A, Class For wires of AWG 24-22.
EA (10 Gbits/s / 500MHz). Without claws.
Equates to cat. 6a, Class EA according to Mounting depth: 31 mm.
ISO/IEC 11801:2011-06. Protection class (Device): IP 20 11
Terminal marking A and B according to TIA/EIA-568-B.2.
Typ according to EN 60 603-7-51:2011-01. 0218/12-101 2CKA000230A0411 1/10
Shielding according to DIN EN 55022, Class B. 1) Suitable for cover plate 1803-02-xxx.
Up to 500 MHz on all pairs of wires.
Suitable for 10-Gigabit Ethernet.
Suitable for PoE+ according to IEEE 802.3at, >- 1.000 Universal data connection box 8(6)/ telephone unit
1
contact durability. 6F+N - connection box )
Flex cable entries from all sides without buckles. 2 x 6-pole
Earthing of housing via 6,3 mm blade terminal at the with straight outlet,
back possible. with screw contacts,
Re-embedded proofed. Universal data-connection boxes: RJ 11/12,
Suitable for Mix-and-Match operation. ISDN capable Cat. 3 in acc. with IEC 603-7/German
Suitable for RJ 11, RJ 12 und RJ 45. Standard DIN EN 60603-7,
For data cables with a diameter of 6 -10 mm. Telecommunication outlet (telephone unit ): for 1
For wires of AWG 24-22. telephone, 1 auxiliary device or 1 data transmission unit,
For trunk systems, flush-mounted wall boxes and With claw.
underfloor systems. Protection class (Device): IP 20
Without claws. white UAE 8(6)TAE 6 F+N 2CKA000230A0381 10/100
Mounting depth: 31 mm. 1) Suitable for cover plate 2539-xxx, 1766-xxx and 1746-2xx-FN.
Protection class (Device): IP 20
0218/11-101 2CKA000230A0409 1/10
Satellite co-axial outlets
1) Suitable for cover plate 1803-xxx.
2 connectors/dead-end feeder
Broadband technology 5-2.400 MHz
For DVB-T, satellite and broad-band cable systems.
For analogue and digital transmission.
With claw.
Minimal installation depth, class A.
Protection class (Device): IP 20
0230-101 2CKA000230A0250 10/100

Antenna socket insert Radio/TV
2 connectors/loop through type
Broadband technology 5-2.400 MHz
For DVB-T, satellite and broad-band cable systems.
For analogue and digital transmission.
With claw.
Minimal installation depth, class A.
Protection class (Device): IP 20
0231-101 2CKA000230A0268 10/100
