carat®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Channel assembly adapter Built-in jack
For the accommodation of one or two universal For potential balancing jack cover plate and installation
modules 0219. in cover plates.
For channel and under-floor installation. For devices of 19 mm diameter.
Suitable for telephone connection unit cover plates Protection class (Device): IP 20
2539-21x and 1766-xxx.
Protection class (Device): IP 20
0471-0-0037 2CKA000471A0037 10
0219/13 2CKA000230A0396 1/10
Potential balancing plug
Universal module, RJ 45, cat. 6a iso, shielded ) Suitable for plug 2095 UC-212 and built-in jack 0471-0-
1
1gang 0037 acc. to German Standard DIN 42801.
For installation in installation adapter 0219/12 or For potential balancing jack cover plate (connection up
0219/13. to 6 mm² crimped or soldered)
Also suited for mounting into cover plate 2561-xxx, Protection class (Device): IP 20
2564-02-xxx and bases 1812, 1866 EB, and 1867 EB.
RJ-45 terminals for networks according to Cat 6A, Class 0299-0-0032 2CKA000299A0032 10
EA (10 Gbits/s / 500MHz).
Equates to cat. 6a, Class EA according to
ISO/IEC 11801:2011-06. Blank plate
Cat. 6A according to ISO/IEC 11801: 2011-06. with metal mounting plate
Terminal marking A and B according to TIA/EIA-568-B.2. Protection class (Device): IP 20
Typ according to EN 60 603-7-51:2011-01.
Shielding according to DIN EN 55022, Class B.
Suitable for PoE+ according to IEEE 802.3at, >- 1.000
contact durability. anthracite 1742-81 2CKA001710A3612 10 11
Bend-radius optimised cable feed (30°).
Earthing of housing via 6,3 mm blade terminal at the ivory white 1742-82 2CKA001710A3143 10
back possible. studio white 1742-84-500 2CKA001710A3991 10/100
Re-embedded proofed.
Suitable for Mix-and-Match operation.
1
For 8-pole plug RJ 45 only. Cover plate )
Housing made from diecast zinc. with flex outlet
With integrated dust-protection cap (can be removed if As cover for flex outlet, for cords up to 10.3 mm
necessary). diameter.
With insulation displacement connection With strain relief (without terminal block).
For data cables with a diameter of 6 -10 mm. Protection class (Device): IP 20
For wires of AWG 24-22.
For trunk systems, flush-mounted wall boxes and anthracite 1749-81 2CKA001710A3614 10
underfloor systems. ivory white 1749-82 2CKA001710A3145 10
Protection class (Device): IP 20 studio white 1749-84 2CKA001710A3163 10/100
0219-101 2CKA000230A0413 1/10 1) Cover plate can also be used individually as cover for telephone connector boxes
1) With assembly adapters appropriate for telephone unit cover plates 2539-21x and (VDo).
1766-xxx.
Cover plate )
1
Modular-Jack insert As cover for universal data connection boxes.
6-pole Cat. 3 (AMP-No. 216000-2) Art.-No. 0213 (Cat 3/ISDN), 0216-101, 0218/11-101 (Cat
For cover plate 2561-xxx, 2561-02-xxx and insert 1812, 5e/6 data technology) and comparable types of the
1866 built-in, 1867 built-in. company Rutenbeck.
For conductor cross-sections of 0.12 mm² (AWG 26) to For WLAN access points 8186/31 and 8186/41.
0.35 mm² (AWG 22). Brand-Rex (WAEGV 8 EKR/EK).
Protection class (Device): IP 20 BTR ( universal data connecting unit design and IAE
design).
0210 2CKA000225A0078 10
Telegärtner (AMJ 45, UMJ 45).
With down-leading outlet.
Modular-Jack insert With labelling field.
8-pole Cat. 3 (AMP-No. 216005-4) Size of labelling field: 60 x 9 mm.
For cover plate 2561-xxx, 2561-02-xxx and insert 1812, Protection class (Device): IP 20
1866 built-in, 1867 built-in. anthracite 1803-81 2CKA001710A3616 10
For conductor cross-sections of 0.12 mm² (AWG 26) to
0.35 mm² (AWG 22). ivory white 1803-82 2CKA001710A3147 10
Protection class (Device): IP 20 studio white 1803-84-500 2CKA001710A1550 10/100
0211 2CKA000225A0086 10 1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
