carat®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Cover plate Intermediate ring with hinged lid )
1
modular jack, Busch-balance® SI
For 2 modular jack inserts. For attaching cover plates from the Busch-balance® SI
Suitable for Art. No. 0210 and 0211. range.
Without claws. Delivery without cover plate.
Protection class (Device): IP 20 With sealing ring.
With hinged lid.
anthracite 2561-02-81 2CKA001753A0317 10 Protection class (Device): IP 44
ivory white 2561-02-82 2CKA001753A0392 10 anthracite 2518-WD-81 2CKA001719A0217 10
studio white 2561-02-84 2CKA001753A0394 10 ivory white 2518-WD-82 2CKA001719A0218 10
studio white 2518-WD-84 2CKA001719A0220 10
Cover plate 1) Combinable only with covers for flush-mounted inserts
50 x 50 mm,
For telecommunication inserts with cover plate
50 x 50 mm. XLR centre plate
With cover plate 50 x 50 mm, AMP, Brand-Rex, As cover for Neutrik plug connectors, type D series.
Rutenbeck, BTR, Telegärtner, etc. Without claws.
Protection class (Device): IP 20 Protection class (Device): IP 20
anthracite 1746/10-81 2CKA001710A3628 10
ivory white 1746/10-82 2CKA001710A3521 10
anthracite 2553-81 2CKA001724A4399 10
studio white 1746/10-84-500 2CKA001710A3993 10/100
ivory white 2553-82 2CKA001724A4400 10
studio white 2553-84 2CKA001724A4402 10
Intermediate ring 11
Reflex SI/SI Linear
For fitting cover plates from the Busch-Duro 2000® SI Cover plate
and Reflex SI range. with metal mounting plate
Protection class (Device): IP 20 For covering universal data communication connectors
and circular connectors with screwed plug M 16x0.75
(installable in insert) in accordance with DIN 41524,
ivory white 1747 SI-82 2CKA001710A3862 10
41529, 45322, 45327, 45328 and 45329.
studio white 1747 SI-84 2CKA001710A3863 10 Knock-out openings 6, 8, 18 mm.
Protection class (Device): IP 20
Intermediate ring anthracite 1748-81 2CKA001710A3654 10
Busch-balance® SI ivory white 1748-82 2CKA001710A3655 10
For attaching cover plates from the Busch-balance® SI
range. studio white 1748-84 2CKA001710A3656 10
Delivery without cover plate.
Protection class (Device): IP 20 Cover plate
anthracite 1747 BSI-81 2CKA001710A4093 10 with metal mounting plate
As cover for BNC and TNC sockets.
ivory white 1747 BSI-82 2CKA001710A4094 10 Knock-out openings 6, 8, 18 mm.
studio white 1747 BSI-84 2CKA001710A4096 10/100 Protection class (Device): IP 20

Cover plate ) 1 anthracite 1750-81 2CKA001710A3617 10
With hinged lid. ivory white 1750-82 2CKA001710A3148 10
For telecommunication inserts with cover plate
50 x 50 mm. studio white 1750-84 2CKA001710A3166 10
With cover plate 50 x 50 mm, AMP, Brand-Rex,
Rutenbeck, BTR, Telegärtner, etc. Equipotential socket outlet
Protection class (Device): IP 20 2gang
anthracite 1746-81 2CKA001710A3618 10 Without claws.
For connecting wires up to 1 x 6 mm² and 4 x 2.5 mm².
ivory white 1746-82 2CKA001710A3149 10
IEC 60601-1:2005; DIN EN 60601 (VDE 0750-1): July 2007
studio white 1746-84 2CKA001710A3167 10 Connection bolts German Standard DIN 42801.
1) Combinable only with covers for flush-mounted inserts Protection class (Device): IP 20
anthracite 2095 UC-81 2CKA002495A0084 10
ivory white 2095 UC-82 2CKA002495A0085 10
studio white 2095 UC-84 2CKA002495A0086 10
