carat®
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Radio iNet ) ) ) ) Busch-Radio BTconnect ) ) ) )
3
2
1
4
4
3
1
2
WLAN Internet radio alarm clock for flush-mounted RDS stereo radio alarm clock for flush-mounted
installation. installation.
For the reception of national and international radio With Bluetooth interface for music replay of mobile
stations via Internet. devices.
Radio station search possible via various genres. Reception frequency: 87.50 MHz - 108.00 MHz.
With high resolution graphic display and background With high resolution graphic display and background
illumination. illumination.
With external AUX input. With external AUX input.
Integrated web-server for configuration and control. For mono/stereo operation.
Remote operation with smartphone via browser surface. 8 radio stations storable.
UPnP replay function. It is controlled via smartphone. With time and date display.
For mono/stereo operation. With alarm clock and snooze function.
8 radio stations storable. With short-time timer.
With time and date display. With automatic switch-off function (automatic sleep
With alarm function. mode).
With short-time timer. With extension input to remote-controlled ON/OFF
With automatic switch-off function (automatic sleep switches.
mode). With integrated antenna.
With extension input to remote-controlled ON/OFF With additional connection for external antenna.
switches. Permitted speaker impedance: 4 - 8 Ohm
With integrated WLAN antenna. Can be installed as 1gang and in multiple combinations.
WLAN Standards: IEEE 802.11b / IEEE 802.11g and IEEE Bluetooth specification: 2.1
802.11n (2,4 GHz). Bluetooth profiles supported: A2DP
WLAN safety: WPA / WPA2. Number of stored Bluetooth connections: max. 8
Permitted speaker impedance: 4 - 8 Ohm Rated voltage: 110 - 230 V~, +10 % / -10 %
Can be installed as 1gang and in multiple combinations. Rated frequency: 50 Hz - 60 Hz 11
Rated voltage: 110 - 230 V~, +10 % / -10 % Protection class (Device): IP 20
Rated frequency: 50 Hz - 60 Hz Temperature range (Device): 5 °C to 40 °C
Protection class (Device): IP 20 Dimensions: (L x W x D): 71 mm x 71 mm x 47 mm
Temperature range (Device): 5 °C to 40 °C Mounting depth: 32 mm
Dimensions: (L x W x D): 71 mm x 71 mm x 49 mm
Mounting depth: 33 mm
8217 U-500 2CKA008200A0194 1

1) No claw. Screw-fixing via keyholes.
8216 U-500 2CKA008200A0153 1/10 2) Matching loudspeaker insert 8223 U.
3) Also combinable with built-in ceiling loudspeaker (8225 EB & 8226 EB) and HiFi
1) No claw. Screw-fixing via keyholes.
2) Matching loudspeaker insert 8223 U. built-in ceiling loudspeaker (8226/11 EB).
4) Can also be combined with built-in loudspeaker (8222 EB) and moist atmosphere
3) Can also be combined with built-in loudspeaker (8222 EB) and moist atmosphere
loudspeaker (8224 EB). loudspeaker (8224 EB).
4) To be mounted only in connection with commercially available flush-mounted
installation boxes according to DIN 49073 > 40 mm depth gauge or Busch-Jaeger
1
4
3
2
art. no. 3040, 3050 or 3060. Busch Bluetooth receiver ) ) ) )
Bluetooth interface for music replay of mobile devices.
With integrated amplifier.
With external AUX input.
For mono/stereo operation.
Can be combined with the MDRC amplifier 8208.
Admissible loudspeaker impedance: 4 - 16 Ohm
Can be installed as 1gang and in multiple combinations.
Bluetooth specification: 4.0
Bluetooth profiles supported: A2DP
Number of stored Bluetooth connections: max. 8
Display elements: LED for status display.
Rated voltage: 110 - 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz
Protection class (Device): IP 20
Temperature range (Device): 5 °C to 40 °C
Dimensions: (L x W x D): 71 mm x 71 mm x 45 mm
Mounting depth: 32 mm

8219 U 2CKA008200A0198 1/10
1) No claw. Screw-fixing via keyholes.
2) Matching loudspeaker insert 8223 U.
3) Also combinable with built-in ceiling loudspeaker (8225 EB & 8226 EB) and HiFi
built-in ceiling loudspeaker (8226/11 EB).
4) Can also be combined with built-in loudspeaker (8222 EB) and moist atmosphere
loudspeaker (8224 EB).
