11/36 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
carat®
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Loudspeaker insert ) Busch-powerDock Charging cradle with USB-C
1
5 cm (2") connection
For Busch-DigitalRadio 8215 U/8216 U. For Busch-powerDock insert 6473 U.
For Busch-Radio iNet 8216 U. For attaching mobile terminal devices with USB-C
For Busch-Radio BTconnect 8217 U. connection.
For Busch Bluetooth receiver 8219 U. Temperature range (Device): 5 °C to 35 °C
With broadband characteristics. Dimensions: (L x W x D): 54 mm x 54 mm x 36 mm
With flat plug connector. 6473/11-500 2CKA006400A0083 1/10
Incl. speaker connection cable.
Rated output: 2 W (RMS)
Frequency response: 200 - 20,000 Hz USB power adapter insert, flush-mounted ) ) ) )
2
3
4
1
Impedance: 4 Ohm For supply and support of mobile devices via USB-cable.
Protection class (Device): IP 20, SELV With two USB type A outputs.
Mounting depth: 32 mm To support two devices at the same time.
8223 U-500 2CKA008200A0183 1/10 With electronic short-circuit protection.
With electronic overload protection.
1) No claw. Screw-fixing via keyholes.
Rated voltage: 100 - 230 V~, +10 % / -10 %
Secondary: 5 V-, +5 % / -5 %
1
2
3
4
Busch-powerDock Insert ) ) ) ) Rated frequency: 50 Hz - 60 Hz
For charging and supplying mobile terminal devices. Suitable for: In case one output is used:
With quick charging function for devices compatible Rated current: 1400 mA
with quick-chargeTM. Suitable for: In case two output are used:
Makes possible fast charging of the mobile terminal Rated current: 700 mA
device. Protection class (Device): IP 20, SELV
Rated voltage: 100 - 230 V~, +10 % / -10 % Temperature range (Device): 5 °C to 40 °C
Rated frequency: 50 Hz - 60 Hz Dimensions: (L x W x D): 71 mm x 71 mm x 43 mm
11
Suitable for: Apple terminal device Mounting depth: 32 mm
Rated current: 2.1 A 6472 U-500 2CKA006400A0002 1
Output voltage: 5 V- 1) No claw. Screw-fixing via keyholes.
Suitable for: Terminal device with USB-C connection 2) No data transfer.
Rated current: 2.1 A 3) For terminal devices with standardized charging interface according to DIN EN
Output voltage: 5 V- 62684.
Suitable for: Terminal device with quick-charge support 4) Use dust cover 2098 when cleaning the device.
and USB-C connection and quick-charge TM function.
Rated current: 2 A USB power adapter insert, flush-mounted ) ) ) )
1
4
2
3
Output voltage: 9 V- For supply and support of mobile devices via USB-cable.
Protection class (Device): IP 20, SELV With two USB type A outputs.
Temperature range (Device): 5 °C to 35 °C To support two devices at the same time.
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm With electronic short-circuit protection.
Mounting depth: 32 mm
With electronic overload protection.
6473 U-500 2CKA006400A0039 1/10 Rated voltage: 120 - 230 V~, +10 % / -10 %
Secondary: 5 V-, +5 % / -5 %
1) No claw. Screw-fixing via keyholes.
2) The USB-C connection of the Busch-powerDock uses the quick charging function Rated frequency: 50 Hz / 60 Hz
according to Qualcomm® Quick chargeTM 2.0 standard. Suitable for: In case one output is used:
3) In rare cases the manufacturers of USB-C terminal devices support the quick- Rated current: 3 A
charging function independent of this standard only in case of charging devices Suitable for: In case two output are used:
that are the same as those of other manufacturers. Rated current: 1.500 mA
4) In these cases the quick-charging function of the terminal device is not enabled.
Protection class (Device): IP 20, SELV
Temperature range (Device): 0 °C to 35 °C
Busch-powerDock Charging cradle with Apple lightning Dimensions: (L x W x D): 71 mm x 71 mm x 43 mm
connection ) Mounting depth: 32 mm
1
For Busch-powerDock insert 6473 U.
For attaching mobile terminal devices with lightning Available from November 2019
connection. 6472 U-500-101 2CKA006400A0094 1
For iPhone XS Max, iPhone XS, iPhone XR, iPhone X. 1) No claw. Screw-fixing via keyholes.
For iPhone 8 Plus, iPhone 8. 2) No data transfer.
For iPhone 7 Plus, iPhone 7. 3) For terminal devices with standardized charging interface according to DIN EN
For iPhone SE. 62684.
For iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6. 4) Use dust cover 2098 when cleaning the device.
For iPhone 5s, iPhone 5c, iPhone 5.
For iPod touch (6th generation), iPod touch (5th
generation), iPod nano (7th generation).
Suitable for use with protective covers certified by
Apple.
Temperature range (Device): 5 °C to 35 °C
Dimensions: (L x W x D): 54 mm x 54 mm x 36 mm
6473-500 2CKA006400A0081 1/10
1) Not released for use with the iPad.
