11/674 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Movement detector
Presence detector

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch movement detector Corridor, decor frame ) Busch-Presence detector mini KNX )
1
1
Paintable decor frame for individual design. 8 meters
For presence detector with Corridor lens. Detection range (for mounting height 2.5 m, 3 m and
For latching onto the presence detector. 4 m): circular.
Temperature range (Device): -5 °C to 45 °C Seated persons Ø: max. 5 m, max. 6.5 m and max. 9 m.
Dimensions: (L x W x D): 94 mm x 94 mm x 27 mm Walking persons Ø: max. 6.5 m, max. 8 m and max.
10.5 m.
studio white 6889/50-24-500 2CKA006800A2801 10 Visible height 16 mm.
matt With 2 channels.
1) The decor frame included in the scope of delivery of the presence detector must be Targeted for connection and disconnection of lights
removed before mounting. bands depending on the room brightness.
Regulation in response to the movement possible.
Using the device as presence and/or movement
Busch extension unit coupling ) detectors.
1
For transmitting different control commands via a Detectors application with 2 power off stages.
single conductor wire. Detectors application with integrated monitoring
For devices with intelligent extension input. function.
For operation via conventional push-buttons 2020 US Constant light switch with up to two independent
and 2021/6 U. channels.
For operation via conventional 2gang push-buttons Constant light switch with max. 2 outputs for
2020 US-205 and 2021/6/6 U. brightness-dependent switching of two light bands in
For universal attachment or installation. the area.
For installation in (deep) flush-mounted boxes to With integrated KNX bus coupler.
German Standard DIN 49073, Part 1. Suitable for false ceilings with a board thickness from
Including compact connecting terminal for cable 9 to 25 mm.
connection. Hole size: Ø 68 mm.
Cable length: approx. 80 mm. Suitable for surface mounting installation.
11
Rated voltage: 110 - 230 V~, +10 % / -10 % Cannot be installed in British Standard or VDE
Rated frequency: 50 Hz - 60 Hz flushmounted box.
Inputs: 2 Recommendation: Installation housing from Kaiser
Protection class (Device): IP 20 HaloX-O (Art.no. 1290-40) with corresponding cover
Temperature range (Device): -5 °C to 45 °C plates (1290-47 or 1290-85 for fair faced concrete) or
Dimensions: (L x W x D): 33 mm x 45 mm x 8.5 mm
IBTronic H120-68 from Spelsberg.
6494-500 2CKA006499A0002 1 Connections:
KNX-line: Bus connection terminal
1) To be mounted only in connection with commercially available flush-mounted
installation boxes according to DIN 49073 > 40 mm depth gauge or Busch-Jaeger Brightness limit value: 1 Lux - 1000 Lux
art. no. 3040, 3050 or 3060. Mounting height: 2 m - 4 m
Protection class (Device): IP 20
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 80 mm x 80 mm x 45 mm
Mounting depth: 29 mm
aluminium 6131/20-183-500 2CKA006132A0343 1
silver
studio white 6131/20-24-500 2CKA006132A0342 1
matt
1) For software and description please check the current Online-Catalogue.
