Busbars TriLine system and pro E power system
Row mounting for modules M(B)R...03

Copper rail A1
Copper rail A2 • It is possible to combine different module widths
within the cabinet with continuous busbars
Copper rail A1
• A connector is required for cabinet row mounting for
each busbar connection
Copper rail C
• The busbar connection is realized outside the module
• Busbar connector for copper 12 x 5 mm and 12 x 10
20 x 5 mm
30 x 5 mm 12 x 5 mm mm, including connection terminals
Copper rail C 30 x 10 mm 12 x 10 mm • Busbar connector for copper 20 x 5 mm, including
press-in nuts and fastening screws
• 3 copper rails A1/A2 and C are required per module

Copper Kit Mounted
rail I n Width not installed and installed in the cabinet
mm A FB mm Unit Type Order code Type Order code
Copper rail A1, busbars for TriLine cabinet row mounting right or left
12 x 5 250 1 267 1 ZX2088 2CPX042573R9999 ZXM2088 2CPX042493R9999
2 517 1 ZX2089 2CPX042574R9999 ZXM2089 2CPX042494R9999
3 767 1 ZX2090 2CPX042575R9999 ZXM2090 2CPX042495R9999
4 1017 1 ZX2091 2CPX042576R9999 ZXM2091 2CPX042496R9999
5 1267 1 ZX2092 2CPX042577R9999 ZXM2092 2CPX042497R9999
12 x 10 360 1 267 1 ZX2100 2CPX042583R9999 ZXM2100 2CPX042503R9999
2 517 1 ZX2101 2CPX042584R9999 ZXM2101 2CPX042504R9999
3 767 1 ZX2102 2CPX042585R9999 ZXM2102 2CPX042505R9999
4 1017 1 ZX2103 2CPX042586R9999 ZXM2103 2CPX042506R9999
5 1267 1 ZX2104 2CPX042587R9999 ZXM2104 2CPX042507R9999
20 x 5 320 1 267 1 ZX2106 2CPX042588R9999 ZXM2106 2CPX042508R9999
2 517 1 ZX2107 2CPX042589R9999 ZXM2107 2CPX042509R9999
3 767 1 ZX2108 2CPX042590R9999 ZXM2108 2CPX042510R9999
4 1017 1 ZX2109 2CPX042591R9999 ZXM2109 2CPX042511R9999
5 1267 1 ZX2110 2CPX042592R9999 ZXM2110 2CPX042512R9999
30 x 5 440 1 267 1 ZX2118 2CPX042598R9999 ZXM2118 2CPX042518R9999
2 517 1 ZX2119 2CPX042599R9999 ZXM2119 2CPX042519R9999
3 767 1 ZX2120 2CPX042600R9999 ZXM2120 2CPX042520R9999
4 1017 1 ZX2121 2CPX042601R9999 ZXM2121 2CPX042521R9999
5 1267 1 ZX2122 2CPX042602R9999 ZXM2122 2CPX042522R9999
30 x 10 630 1 267 1 ZX2124 2CPX042603R9999 ZXM2124 2CPX042523R9999
2 517 1 ZX2125 2CPX042604R9999 ZXM2125 2CPX042524R9999
3 767 1 ZX2126 2CPX042605R9999 ZXM2126 2CPX042525R9999
4 1017 1 ZX2127 2CPX042606R9999 ZXM2127 2CPX042526R9999
5 1267 1 ZX2128 2CPX042607R9999 ZXM2128 2CPX042527R9999
