Busbars TriLine system and pro E power system
Row mounting for modules M(B)T...50+51(B)

Copper rail A1
Copper rail A2 • It is possible to combine different module widths
within the cabinet with continuous busbars
Copper rail A1
• A connector is required for cabinet row mounting for
each busbar connection
• The busbar connection is realized outside the module
• Busbar connector, including connection terminals
• 3 copper rails A1/A2 and C are required per module
Connector C

Copper Kit Mounted
rail I n Width not installed and installed in the cabinet
mm A FB mm Unit Type Order code Type Order code
Copper rail A1, busbars for cabinet row mounting right or left
12 x 5 250 2 543 1 ZX1041 2CPX041907R9999 ZXM1041 2CPX041517R9999
3 793 1 ZX1042 2CPX041908R9999 ZXM1042 2CPX041518R9999
4 1043 1 ZX1043 2CPX041909R9999 ZXM1043 2CPX041519R9999
5 1293 1 ZX1044 2CPX041910R9999 ZXM1044 2CPX041520R9999
12 x 10 360 2 543 1 ZX1047 2CPX041913R9999 ZXM1047 2CPX041523R9999
3 793 1 ZX1048 2CPX041914R9999 ZXM1048 2CPX041524R9999
4 1043 1 ZX1049 2CPX041915R9999 ZXM1049 2CPX041525R9999
5 1293 1 ZX1050 2CPX041916R9999 ZXM1050 2CPX041526R9999
Copper rail A2, busbars for cabinet row mounting right and left
12 x 5 250 2 595 1 ZX1081 2CPX041943R9999 ZXM1081 2CPX041553R9999
3 845 1 ZX1082 2CPX041944R9999 ZXM1082 2CPX041554R9999
4 1095 1 ZX1083 2CPX041945R9999 ZXM1083 2CPX041555R9999
5 1345 1 ZX1084 2CPX041946R9999 ZXM1084 2CPX041556R9999
12 x 10 360 2 590 1 ZX1087 2CPX041949R9999 ZXM1087 2CPX041559R9999
3 840 1 ZX1088 2CPX041950R9999 ZXM1088 2CPX041560R9999
4 1090 1 ZX1089 2CPX041951R9999 ZXM1089 2CPX041561R9999
5 1340 1 ZX1090 2CPX041952R9999 ZXM1090 2CPX041562R9999
Copper rail C, connector for TwinLine cabinet row mounting right or left
12 x 5 250 44 1 ZX1180 2CPX042020R9999 - -
12 x 10 360 44 1 ZX1181 2CPX042021R9999 - -
Copper rail C, connector for the pro E power system cabinet row mounting right or left
12 x 5 250 44 1 ZX1180 2CPX042020R9999 - -
12 x 10 360 44 1 ZX1181 2CPX042021R9999 - -
