11/670 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Movement detector
Presence detector

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Presence detector Universal BT, e-contact with Busch-Presence detector Corridor BT, relay ) ) ) 3
1
2
sealing ring ) ) ) 30 metres
1
2
3
12 meters Master presence detector with mixed light measurement.
Master presence detector with mixed light measurement. For switching lighting systems that depend on
For switching lighting systems that depend on brightness and movement. With Bluetooth interface
brightness and movement. With Bluetooth interface for parameterization and operation. Adjustment of all
for parameterization and operation. Adjustment of all setting options via smartphone or tablet. Light control via
setting options via smartphone or tablet. smartphone or tablet app. With power relays for LED
Light control via smartphone or tablet app. operation.
With electronic switch contact for LED operation. Detection range (for installation height of 3 m):
With selectable soft ON/OFF function. rectangular
Detection range (for installation height of 3 m): circular Walking persons: crosswise to the detector 30 m x 3 m,
Seated persons: up to Ø 10 m, walking persons: up to frontal 20 m x 3 m.
Ø 12 m. Extension of the detection range by means of Extension of the detection range by means of master/
master/slave combination. Visible height 23 mm. slave combination.
For semi-automatic, comfort and fully automatic Mounting height 27 mm.
operation. For semi-automatic, comfort and fully automatic operation.
Additional activation/deactivation possibility through Additional activation/deactivation possibility through
pushbutton input. pushbutton input. With continuous light/continuous off
With continuous light/continuous off function (8 hours), function (8 hours), activation via intelligent extension
activation via intelligent extension unit input possible. unit input possible. With selectable presence simulation
With selectable presence simulation in case of non- in case of non-presence. With integrated storage of ON
presence. period (energy monitor). With brightness-independent
With integrated storage of ON period (energy monitor). test mode for evaluating the detection zone.
With brightness-independent test mode for evaluating With teach-in function of the brightness switching
the detection zone. threshold, IR service remote control required.
With teach-in function of the brightness switching With detection display in test mode. Ceiling installation
11
threshold, IR service remote control required. using integrated spring bracket. Twist protection via
With detection display in test mode. additional quick tensioning. Adjustment elements
Ceiling installation using integrated spring bracket. accessible on the front side.
Twist protection via additional quick tensioning. Surveillance density: 92 sectors with 368 switching
Adjustment elements accessible on the front side. segments
Surveillance density: 72 sectors with 640 switching Individual deactivation and adjustment of sensitivity of
segments. individual sensors possible.
Individual deactivation and adjustment of sensitivity of Switch-off delay: approx. 1 min. - 30 min. or short-time
individual sensors possible. pulse adjustable.
Switch-off delay: approx. 1 min. - 30 min. or short-time With selectable dynamic switch-off delay.
pulse adjustable. Suitable for false ceilings with a board thickness from
With selectable dynamic switch-off delay. 9 to 25 mm.
Suitable for false ceilings with a board thickness from Hole size: Ø 68 mm.
9 to 25 mm. Control element: 2 controllers for setting the brightness
Hole size: Ø 68 mm. switching threshold and switch-off delay.
Control element: 2 controllers for setting the brightness Display elements: LED detection and status indication.
switching threshold and switch-off delay. Rated voltage: 110 - 230 V~, +10 % / -10 %
Display elements: LED detection and status indication. Rated frequency: 50 Hz - 60 Hz
Rated voltage: 110 - 230 V~, +10 % / -10 % Outputs: 1x Normally open contact, potential-bound
Rated frequency: 50 Hz - 60 Hz Suitable for: 230 V incandescent lamps
Outputs: 1x Normally open contact, potential-bound Rated power: 2300 W
Suitable for: 230 V incandescent lamps Suitable for: 230 V~ LEDi
Rated power: 3 - 200 W Rated power: 200 W/VA
Suitable for: 230 V~ LEDi Suitable for: Fluorescent lamps
Rated power: 3 - 200 W/VA Rated current: 10 AX, cos φ 0.9
Detection angle: 360 ° Detection angle: 360 °
Brightness limit value: 5 Lux - 2000 Lux Brightness limit value: 5 Lux - 2000 Lux
Mounting height: 2 m - 4 m Mounting height: 2 m - 4 m
Protection class (Device): IP 41 Protection class (Device): IP 40
Temperature range (Device): -5 °C to 45 °C Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 94 mm x 94 mm x 59 mm Dimensions: (L x W x D): 94 mm x 94 mm x 76 mm
Mounting depth: 36 mm60669-2-1 Mounting depth: 49 mm60669-2-1
LEDi LEDi

alpine white 6817/93-204-500 2CKA006800A2803 1 studio white 6819/51-24-500 2CKA006800A2745 1
aluminium 6817/93-183-500 2CKA006800A2805 1 matt
silver aluminium 6819/51-183-500 2CKA006800A2779 1
1) The detection range with a central approach is reduced. silver
2) Free app for iOS and Android available in the App Store or Play Store. 1) In combination with a relay/contactor, an RC suppressor 6899 has to be used.
3) Recommendation: HaloX-O flush-mounted box from Kaiser (article no. 1290-40) 2) Free app for iOS and Android available in the App Store or Play Store.
with corresponding cover (1290-47 or 1290-85 for exposed concrete) or IBTronic 3) Recommendation: HaloX-O flush-mounted box from Kaiser (article no. 1290-40)
H120-68 from Spelsberg with corresponding cover (1290-47 or 1290-85 for exposed concrete) or IBTronic
H120-68 from Spelsberg
