11/668 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Movement detector
Presence detector

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-Presence detector Universal, e-contact ) ) Busch-Presence detector Corridor, relay ) )
2
2
1
12 meters 24 meters
Master presence detector with mixed light Master presence detector with mixed light
measurement. measurement.
For switching lighting systems that depend on For switching lighting systems that depend on
brightness and movement. brightness and movement.
With electronic switch contact for LED operation. With power relays for LED operation.
Detection range (for installation height of 3 m): circular Detection range (for installation height of 3 m):
Seated persons: up to Ø 10 m, walking persons: up to rectangular
Ø 12 m. Walking persons: crosswise to the detector 24 m x 3 m,
Extension of the detection range by means of master/ frontal/lengthways to the detector 14 m x 3 m.
slave combination. Extension of the detection range by means of master/
Visible height 23 mm. slave combination.
For semiautomatic and fully automatic operation. Mounting height 27 mm.
Additional activation/deactivation possibility through For semiautomatic and fully automatic operation.
pushbutton input. Additional activation/deactivation possibility through
With continuous light/continuous off function (8 hours), pushbutton input.
activation via intelligent extension unit input possible. With continuous light/continuous off function (8 hours),
With brightness-independent test mode for evaluating activation via intelligent extension unit input possible.
the detection zone. With brightness-independent test mode for evaluating
With teach-in function of the brightness switching the detection zone.
threshold, IR service remote control required. With teach-in function of the brightness switching
With detection display in test mode. threshold, IR service remote control required.
Ceiling installation using integrated spring bracket. With detection display in test mode.
Twist protection via additional quick tensioning. Ceiling installation using integrated spring bracket.
Adjustment elements accessible on the front side. Twist protection via additional quick tensioning.
Surveillance density: 72 sectors with 640 switching Adjustment elements accessible on the front side.
11
segments. Surveillance density: 92 sectors with 368 switching
Switch-off delay: approx. 1 min. - 30 min. or short-time segments
pulse adjustable. Switch-off delay: approx. 1 min. - 30 min. or short-time
Remote control possible via IR service remote control pulse adjustable.
6843. Remote control possible via IR service remote control
Suitable for false ceilings with a board thickness from 6843.
9 to 25 mm. Suitable for false ceilings with a board thickness from
Hole size: Ø 68 mm. 9 to 25 mm.
Control element: 2 controllers for setting the brightness Hole size: Ø 68 mm.
switching threshold and switch-off delay. Control element: 2 controllers for setting the brightness
Display elements: LED detection and status indication. switching threshold and switch-off delay.
Rated voltage: 110 - 230 V~, +10 % / -10 % Display elements: LED detection and status indication.
Rated frequency: 50 Hz - 60 Hz Rated voltage: 110 - 230 V~, +10 % / -10 %
Outputs: 1x Normally open contact, potential-bound Rated frequency: 50 Hz - 60 Hz
Suitable for: 230 V incandescent lamps Outputs: 1x Normally open contact, potential-bound
Rated power: 3 - 200 W Suitable for: 230 V incandescent lamps
Suitable for: 230 V~ LEDi Rated power: 2300 W
Rated power: 3 - 200 W/VA Suitable for: 230 V~ LEDi
Detection angle: 360 ° Rated power: 200 W/VA
Brightness limit value: 5 Lux - 2000 Lux Suitable for: Fluorescent lamps
Mounting height: 2 m - 4 m Rated current: 10 AX, cos φ 0.9
Protection class (Device): IP 40 Detection angle: 360 °
Temperature range (Device): -5 °C to 45 °C Brightness limit value: 5 Lux - 2000 Lux
Dimensions: (L x W x D): 94 mm x 94 mm x 59 mm Mounting height: 2 m - 4 m
Mounting depth: 36 mm60669-2-1 Protection class (Device): IP 40
Temperature range (Device): -5 °C to 45 °C
LEDi Dimensions: (L x W x D): 94 mm x 94 mm x 76 mm
studio white 6817/32-24-500 2CKA006800A2739 1 Mounting depth: 49 mm60669-2-1
matt LEDi
aluminium 6817/32-183-500 2CKA006800A2773 1
silver studio white 6819/50-24-500 2CKA006800A2797 1
matt
1) The detection range with a central approach is reduced.
2) Recommendation: HaloX-O flush-mounted box from Kaiser (article no. 1290-40) aluminium 6819/50-183-500 2CKA006800A2799 1
with corresponding cover (1290-47 or 1290-85 for exposed concrete) or IBTronic silver
H120-68 from Spelsberg 1) In combination with a relay/contactor, an RC suppressor 6899 has to be used.
2) Recommendation: HaloX-O flush-mounted box from Kaiser (article no. 1290-40)
with corresponding cover (1290-47 or 1290-85 for exposed concrete) or IBTronic
H120-68 from Spelsberg
