11/673

—
Movement detector
Presence detector

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-Presence detector Corridor, slave, DALI ) Busch-Presence detector Universal, sensor ) ) )
1
3
2
30 metres 12 meters
DALI slave presence detector for extension of the Master presence detector with mixed light
detection range of DALI master presence detectors. measurement.
For the supply of operating voltage via the DALI master. For switching lighting systems that depend on
Power consumption on the DALI bus: max. 10 mA, brightness and movement.
corresponds to approx. 5 DALI operating devices. Detection range (for installation height of 3 m): circular
The communication with the DALI master is carried out Seated persons: up to Ø 10 m, walking persons: up to
via the DALI interface. Ø 12 m.
Detection range (for installation height of 3 m): Extension of the detection range by means of master/
rectangular slave combination.
Walking persons: crosswise to the detector 24 m x 3 m, Mounting height: 35 mm
frontal/lengthways to the detector 14 m x 3 m. For semiautomatic and fully automatic operation.
Mounting height 27 mm. Additional activation/deactivation possibility through
Ceiling installation using integrated spring bracket. pushbutton input.
Twist protection via additional quick tensioning. With continuous light/continuous off function (8 hours),
Surveillance density: 92 sectors with 368 switching IR service remote control required.
segments. With teach-in function of the brightness switching
Suitable for false ceilings with a board thickness from threshold, IR service remote control required.
9 to 25 mm. With brightness-independent test mode for evaluating
Hole size: Ø 68 mm. the detection zone.
Rated voltage: 95 - 22.5 V- With detection display in test mode.
Detection angle: 360 ° Remote control possible via IR service remote control
Mounting height: 2 m - 4 m 6843.
Protection class (Device): IP 40 Adjustment elements accessible on the front side.
Temperature range (Device): -5 °C to 45 °C Surveillance density: 72 sectors with 640 switching
Dimensions: (L x W x D): 94 mm x 94 mm x 76 mm segments. 11
Mounting depth: 49 mm Switch-off delay: approx. 1 min. - 30 min. or short-time
pulse adjustable.
For Busch-Universal relay switch insert 6440/01 U-500.
studio white 6819/59-24-500 2CKA006800A2761 1 For Universal-e-contact insert 6440/04 U-500.
matt For Universal-Slave insert 6440/05 U-500.
aluminium 6819/59-183-500 2CKA006800A2795 1 Control element: 2 controllers for setting the brightness
silver switching threshold and switch-off delay.
Display elements: LED detection and status indication.
1) Recommendation: HaloX-O flush-mounted box from Kaiser (article no. 1290-40)
with corresponding cover (1290-47 or 1290-85 for exposed concrete) or IBTronic Detection angle: 360 °
H120-68 from Spelsberg Brightness limit value: 5 Lux - 2000 Lux
Mounting height: 2 m - 4 m
Protection class (Device): IP 40
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 94 mm x 94 mm x 43 mm
DIN EN 60669-2-1
studio white 6813-24-102-500 2CKA006800A2861 1
matt
aluminium 6813-183-102-500 2CKA006800A2863 1
silver
1) The detection range with a central approach is reduced.
2) The range specifications refer to an ambient temperature of 21 °C.
3) Please order the respective flush-mounted insert separately.

Busch-Presence detector Universal, decor frame )
1
Paintable decor frame for individual design.
For presence detectors with Compact and Universal
lens.
For latching onto the presence detector.
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 94 mm x 94 mm x 23 mm
studio white 6889/30-24-500 2CKA006800A2765 10
matt
1) The decor frame included in the scope of delivery of the presence detector must be
removed before mounting.
