Interior expansion system CombiLine N
Busbar system, vertical, M(B)S...28, MBW250A

• With 4-pole busbars 30 x 5 mm, bores with M6 thread
as well as connection with M8 press-in nuts for access
• With busbar bracket type ZX518
• Rated current (I ) 440 A
n
• The mounting frame must be ordered separately
• Not suitable for fire protection housing

MS128

Kit Mounted
Height Width From cabinet depth not installed and installed in the cabinet
Re mm FB mm PLE EDF* WR* 2 mm Type Order code Type Order code
1
2 300 1 250 24   200 MBS128 2CPX041648R9999 MS128 2CPX041123R9999
3 450 2 500 72   200 MBS228 2CPX041649R9999 MS228 2CPX041124R9999
* 1 Expansion on EDF mounting frame | * 2 Expansion on WR mounting frame

• With 3-pole busbars 30 x 5 mm and removable
transformer supports
• With busbar bracket ZX146
• With deep angle piece ZW59P2
• With bus-mounting fuse socket E27, width 42 mm,
3-pole
• With cover with transparent panel
• Rated current (I ) 250 A
n
• The mounting frame must be ordered separately
• Not suitable for fire protection housing

MBW250A
Kit Mounted
Height Width From cabinet depth not installed and installed in the cabinet
1
Re mm FB mm PLE EDF* WR* 2 mm Type Order code Type Order code
3 450 1 250 36   215 MBW250A 2CPX042102R9999 - -
* 1 Expansion on EDF mounting frame | * 2 Expansion on WR mounting frame
